1979 Yamaha YZ400F (YZ400F) Front Wheel Diagram

← All diagrams

Find the part on the Front Wheel diagram for your 1979 Yamaha YZ400F (YZ400F), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Yamaha YZ400F (YZ400F) Front Wheel Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HUB, FRONT

1K7-25111-10-98

1
Out of stock

2

SPOKE SET, FRONT

2W6-25104-02-00

1
Out of stock

3

SPOKE SET, INNER 1

(2W6-25196-90-00)

1
Out of stock

4

SPOKE SET, OUTER 1

(2W6-25197-90-00)

1
Out of stock

5

SPOKE SET, INNER 2

(2W6-25179-90-00)

1
Out of stock

6

SPOKE SET, OUTER 2

(2W6-25189-90-00)

1
Out of stock

7

RIM 1.60X21

94416-21326-00

1
Out of stock

8

300-21 M1B (TT)

(94130-213A4-00)

1
Out of stock

9

TUBE

94230-21126-00

1
Out of stock

10

BAND, RIM

(94330-21088-00)

1
Out of stock

11

SPACER, BEAD

1T1-25194-00-00

—

$53.98

In stock

12

SPACER

90560-15116-00

1
Out of stock

13

FLANGE, SPACER

146-25116-00-00

1
Out of stock

14

BEARING

93306-20205-00

1

$32.63

In stock

15

OIL SEAL (20X35X7-136)

93102-20009-00

1

$9.10

In stock

16

BEARING(3DL)

93306-20226-00

—

$33.15

In stock

17

BRAKE SHOE PLT ASSEMBLY (1W1-25121-02-98)

1W1-25016-11-98

1
Out of stock

18

BRAKE SHOE KIT

322-W253A-10-00

—

$31.99

In stock

19

SPRING (5T9)

90506-17328-00

—

$9.32

In stock

20

CAMSHAFT

23X-25151-00-00

1
Out of stock

21

SEAL, CAMSHAFT

137-25159-00-00

1
Out of stock

22

LEVER, CAMSHAFT 1

322-25155-00-00

1
Out of stock

23

BOLT, HEXAGON (462)

90101-06291-00

—

$6.68

In stock

24

AXLE, WHEEL

509-25181-00-00

1
Out of stock

25

COVER, HUB DUST

322-25118-00-00

—

$16.17

In stock

26

COLLAR (34L)

90387-152J3-00

—

$18.75

In stock
