Yamaha YZ400F (YZ400F) 1979 C - D - I - MAGNETO Diagram

#

Description
Price

1

CDI MAGNETO ASSEMBLY

(2X5-85500-20-00)

Unavailable

2

. ROTOR ASSEMBLY

2X7-85550-20-00

Unavailable

3

. BASE, MAGNETO

1M2-85509-20-00

Unavailable

4

COIL SOURCE 2

(2X7-85512-20-00)

Unavailable

5

SCREW, PAN HEAD(4MY)

98507-05018-00

$3.28

6

SCREW, PANHEAD (A93)

98580-05525-00

$2.00

7

YBS67-5 WASHER, SPRING

92990-05100-00

$0.35

8

. COIL, PULSER

2X9-85580-20-00

Unavailable

9

SCREW, PAN HEAD

98507-04018-00

$2.19

10

YBS67-4 WASHER, SPRING

92990-04100-00

$0.86

11

LEAD WIRE ASSEMBLY

(2X5-85515-20-00)

Unavailable

12

CLAMP, LEAD

104-81328-20-00

$6.99

13

SCREW, PAN HEAD(3XP)

98517-04006-00

Unavailable

14

YBS67-4 WASHER, SPRING

92990-04100-00

$0.86

15

SCREW PAN HEAD

98580-06020-00

$8.49

16

WASHER, PLAIN (646)

92990-06600-00

Unavailable
