Yamaha YZ250S1 (YZ250) 5XF1 2004 ELECTRICAL 1 Diagram

#

Description

Price

1

C.D.I. UNIT ASSY

5NX-85540-01-00

Unavailable

2

BAND

5NY-85546-00-00

Unavailable

3

IGNITION COIL ASSY

4MX-82310-02-00

Unavailable

4

BOLT, WASHER BASED(JA9)

90105-06696-00

$9.49

5

PLUG CAP ASSY

8DG-82370-00-00

$49.99

6

CLAMP(4FM)

90464-15195-00

$4.41

7

CLAMP

90464-76001-00

Unavailable

8

CLAMP(4FM)

90464-15195-00

$4.41

9

CLAMP

90464-76001-00

Unavailable

10

CLAMP

90464-76001-00

Unavailable

11

CLAMP(4FM)

90464-15195-00

$4.41

12

WIRE, SUB LEAD

5XF-82509-00-00

Unavailable
