Yamaha YZ250FP (YZ250F) 5SG1 2002 HANDLE SWITCH LEVER Diagram

#

Description
Price

1

HOLDER, LEVER 1

5HD-82911-00-00

$19.67

2

H0LDER, LEVER L0WER 1

38V-82913-00-00

$17.82

3

LEVER 1

5MV-83912-01-00

$28.15

4

BOLT

90109-06027-00

$8.13

5

NUT, SELF-LOCKING

95617-06100-00

$2.17

6

BOLT(4TW)

97017-05016-00

$2.31

7

BOLT, ADJUSTING

5HD-26337-00-00

$8.92

8

BOLT, CABLE ADJUST

5HD-83951-01-00

$35.81

9

COVER, HANDLE LEVER 1

5HD-26372-00-00

$14.07

10

SWITCH, HANDLE 1

5SF-83976-00-00

Unavailable

11

LEVER, DECOMPRESSION

583-83981-00-00

$19.11

12

COLLAR, LEVER 1

5BE-83913-00-00

$4.38

13

SCREW, BINDING

98907-05020-00

$5.76

14

NUT, U

95617-05100-00

$6.22

15

HOLDER, LEVER UPPER 1

5BE-82912-00-00

$44.41

16

H0LDER, LEVER L0WER 1

38V-82913-00-00

$17.82

17

BOLT(4TW)

97017-05016-00

$2.31

18

COVER, DECOMPRESSION WIRE

583-26352-00-00

Unavailable
