Yamaha YZ250FN (YZ250F) 5NL1 2001 HANDLE SWITCH LEVER Diagram

#

Description
Price

1

HOLDER, LEVER 1

5HD-82911-00-00

$25.99

2

H0LDER, LEVER L0WER 1

38V-82913-00-00

$23.99

3

LEVER 1

5MV-83912-01-00

$34.99

4

BOLT

90109-06027-00

$11.49

5

NUT, SELF-LOCKING

95617-06100-00

$8.49

6

BOLT(4TW)

97017-05016-00

$3.29

7

BOLT, ADJUSTING

5HD-26337-00-00

$11.99

8

BOLT, CABLE ADJUST

5HD-83951-01-00

$44.99

9

COVER, HANDLE LEVER 1

5HD-26372-00-00

$17.49

10

SWITCH, HANDLE 1

23X-83976-01-00

Unavailable

11

LEVER, DECOMPRESSION

583-83981-00-00

$25.99

12

COLLAR, LEVER 1

5BE-83913-00-00

$4.84

13

SCREW, BINDING

98907-05020-00

$8.49

14

NUT, U

95617-05100-00

$9.49

15

HOLDER, LEVER UPPER 1

5BE-82912-00-00

$47.99

16

H0LDER, LEVER L0WER 1

38V-82913-00-00

$23.99

17

BOLT(4TW)

97017-05016-00

$3.29

18

COVER, DECOMPRESSION WIRE

583-26352-00-00

Unavailable
