REAR WHEEL
Yamaha YZ250F (YZ250F) 1979 REAR WHEEL Diagram
#
1
HUB, REAR
(483-25311-13-98)
Unavailable
2
SPOKE SET, REAR (431-25304-00)
431-25304-01-00
Unavailable
3
SPOKE SET, INNER 2
(431-25396-90-00)
Unavailable
4
SPOKE SET, INNER 1
(431-25391-90-00)
Unavailable
5
SPOKE SET, OUTER 1
(431-25392-90-00)
Unavailable
6
150/80-18 M2A (TT) (94151-18684) (4.50-18-4PR)
94115-186A2-00
Unavailable
7
TUBE
94245-18125-00
Unavailable
8
RIM 2.15X18 (94421-18151) (2.15-18)
94421-18238-00
Unavailable
10
SPACER,BEAD
1T1-25394-01-00
Unavailable
11
SPACER, BEARING
483-25317-01-00
Unavailable
12
FLANGE, SPACER
483-25315-00-00
Unavailable
15
COLLAR
(90387-17700-00)
Unavailable
16
PLATE, BRAKE SHOE
(2X4-25321-00-98)
Unavailable
17
BRAKE SHOE KIT
3BH-W253E-00-00
Unavailable
18
SPRING, TENSION 2462533300
90507-20002-00
Unavailable
19
SHIM, CAM SHAFT
148-25353-00-00
Unavailable
20
CAMSHAFT
1E6-25151-00-00
Unavailable
21
SEAL, CAM SHAFT
148-25359-00-00
Unavailable
22
LEVER, CAMSHAFT
2X4-25355-00-00
Unavailable
23
BOLT, HEXAGON (538)
90101-06278-00
Unavailable
24
NUT, HEXAGON
95380-06600-00
Unavailable
25
O-RING
93210-31MJ5-00
Unavailable
26
COVER, PLATE
275-25327-00-00
Unavailable
27
COLLAR
(90387-17651-00)
Unavailable
28
PULLER, CHAIN 1
2K8-25388-00-00
Unavailable
29
. NUT
95380-08700-00
Unavailable
30
BOLT
90101-08060-00
Unavailable
31
BUSH, SOLID
90381-17027-00
Unavailable
32
AXLE, WHEEL
2K8-25381-00-00
Unavailable
33
BAR, TENSION
2X4-25371-00-00
Unavailable
34
BOLT, WITH HOLE
90102-08034-00
Unavailable
35
OIL SEAL
93104-12003-00
Unavailable
36
COLLAR
90387-08699-00
Unavailable
37
NUT, U
95617-08100-00
Unavailable
38
PIN, COTTER
91490-20025-00
Unavailable
39
BOLT, STUD (483)
90116-08218-00
Unavailable
40
SPROCKET, DRIVN 48T
(431-25448-04-XX)
Unavailable
40
SPROCKET, DRIVN 50TSPROCKET WHEEL (50T)
431-25450-04-XX
Unavailable
40
SPROCKET, DRIVN 52T
(431-25452-04-XX)
Unavailable
41
WASHER
2XJ-25412-00-00
Unavailable
42
NUT (583)
90170-08193-00
Unavailable
43
OIL SEAL (25X40X8-248)
93102-25061-00
Unavailable
44
COVER, HUB DUST
431-25367-00-00
Unavailable
45
COLLAR
90387-17650-00
Unavailable
46
WASHER(JN5)
92907-16100-00
Unavailable
47
NUT, HEXAGON
90170-16177-00
Unavailable
48
520 DS 108L (520DS-108L)
94585-20108-00
Unavailable
49
. JOINT CHAIN
94680-11001-00
Unavailable
