Yamaha YZ250F (YZ250F) 1979 REAR ARM Diagram

#

Description
Price

1

REAR ARM

(2X4-22110-01-35)

Unavailable

2

BEARING, THRUST

93342-22205-00

$70.99

3

BRG,CYL-CAL ROLLER 14.5G TM

93317-22214-00

$47.99

4

BUSH, SOLID

90380-16056-00

Unavailable

5

WASHER, PLATE

90201-22284-04

$2.82

6

COVER, THRUST 2

2X4-22129-00-00

Unavailable

7

OIL SEAL (35X41.5X8-483)

93108-35004-00

$15.99

8

OIL SEAL, SDO-TYPE

93109-22018-00

Unavailable

9

SEAL, GUARD

431-22151-03-00

$27.99

10

SHAFT, PIVOT

1W4-22141-00-00

Unavailable

11

NUT

90170-16111-00

Unavailable

12

WASHER(JN5)

92907-16100-00

$14.99

13

GUARD, CHAIN

3R5-22153-00-00

Unavailable

14

BOLT

97013-08035-00

$5.60

15

YBS67-8 WASHER, SPRING

92990-08100-00

$5.60

16

.. WASHER, PLATE

92990-08600-00

Unavailable

17

ARM, TENSIONER

2X4-22179-00-00

Unavailable

18

SUPPORT, CHAIN

2X4-22199-00-00

Unavailable

19

BOLT(JA9)

90101-08691-00

Unavailable

20

YBS67-8 WASHER, SPRING

92990-08100-00

$5.60

21

.. WASHER, PLATE

92990-08600-00

Unavailable

22

SCREW PAN HEAD

98580-06020-00

Unavailable

23

WASHER, SPRING

92995-06100-00

Unavailable

24

WASHER, PLAIN (646)

92990-06600-00

Unavailable

25

BOLT, HEXAGON

97013-06050-00

Unavailable

26

NUT, SELF-LOCKING

95617-06100-00

Unavailable

27

PROTECTOR, CHAIN

3R4-22147-00-00

Unavailable

28

BOLT, HEXAGON

97013-05010-00

Unavailable

29

YBS67-5 WASHER, SPRING

92990-05100-00

Unavailable

30

. WASHER, PLAIN

92990-05200-00

Unavailable

31

BOLT

90109-08480-00

Unavailable

32

NUT, SPEC''L SHAPE

90179-08243-00

Unavailable

33

PIN, COTTER

91490-20025-00

Unavailable

34

PIN,CLEVIS

90240-12059-00

Unavailable

35

WASHER, PLATE(663)

92990-12600-00

Unavailable

36

PIN, COTTER

91490-30030-00

Unavailable

37

COVER, THRUST

1W1-22128-00-00

Unavailable

38

BUSH, SOLID

(90381-12030-00)

Unavailable
