Yamaha YZ125S1 (YZ125) 5XE1 2004 REAR SUSPENSION Diagram

SHOCK ABSORBER ASSY, REAR

5XE-22210-00-00

Unavailable

. DAMPER SUB ASSY

5XE-22201-00-00

Unavailable

GUIDE, SPRING 3

3SP-22234-00-00

$43.99

SEAT, SPRING UPPER

3SP-22213-00-00

$46.99

CAP, AIR VALVE

509-23184-L0-00

$6.99

BUSH, SHOCK ABSORBER LOWER

4JX-22226-00-00

$51.99

CIRCLIP

5DH-23183-00-00

$5.49

SPRING (K=44N/MM)

5UN-22212-10-00

Unavailable

GUIDE, SPRING 1

5XE-22214-00-00

Unavailable

GUIDE, SPRING 2

5MV-22224-00-00

$24.99

. COLLAR, DISTANCE

5DH-22253-00-00

Unavailable

SEAL, DUST

3JE-22475-00-00

$13.49

SEAL, RING

4EW-22474-00-00

$6.99

BEARING

5MV-22176-00-00

$39.99

BUSH

5MV-22184-00-00

$25.99

COLLAR, DISTANCE

5MV-22253-00-00

Unavailable

SEAL, DUST

5NY-22475-00-00

Unavailable

BOLT 2

5XE-22242-01-00

Unavailable

NUT, SELF-LOCKING(JN5)

95607-10200-00

Unavailable

BOLT 1

5NY-22241-00-00

Unavailable

NUT, SELFLOCKING (533 FRAME)

90185-10060-00

Unavailable
