Yamaha YZ125N (YZ125N) 1985 GOVERNOR Diagram
#
Description
Price
1
LEVER
5X4-11931-00-00
Unavailable
3
PUSH ROD ASSEMBLY
24X-11990-00-00
Unavailable
7
FORK, GOVERNOR
5X4-11922-00-00
Unavailable
11
GEAR, GOVERNOR
24X-11953-01-00
Unavailable
13
SPRING, COMPRESSION
90501-30742-00
Unavailable
14
PLATE
5X4-11952-00-00
Unavailable
16
COLLAR (5X4)
90387-152F2-00
Unavailable
17
BUSH, SOLID
90380-15104-00
Unavailable
18
RETAINER
5X5-11911-01-00
Unavailable
19
RETAINER
5X5-11911-01-00
Unavailable
20
BALL (5X4)
93521-64032-00
Unavailable
21
PIN, DOWEL (5X4)
93603-14179-00
Unavailable
22
WASHER, PLATE (5X5)
90201-154F5-00
Unavailable
23
WASHER, PLATE
90201-154F6-00
Unavailable
24
PIN, DOWEL
93603-13185-00
Unavailable
