Description

Price

1

GEAR, PRIMARY DRIVE

3XJ-16111-00-00

Unavailable

2

COLLAR(2RH)

90387-202T9-00

$36.99

3

BOLT, WASHER BASED(1TX)

90105-10445-00

$11.49

4

PRIMARY DRIVEN GEAR COMP.

5NY-16150-00-00

$462.99

5

BOSS, CLUTCH

5NY-16371-00-00

$88.99

6

PLATE, CLUTCH 1

3XJ-16324-10-00

$13.49

7

PLATE, FRICTION

3XJ-16321-00-00

$22.99

8

PLATE, PRESSURE 1

4EX-16351-00-00

Unavailable

9

SPRING (583 CLUTCH)

90501-23391-00

$7.49

10

SCREW, WITH WASHER (1W4)

90159-06016-00

$8.49

11

ROD, PUSH 1

3SB-16356-10-00

Unavailable

12

BEARING, THRUST(3AY)

93340-21008-00

$29.99

13

WASHER, PLATE(1HX)

90201-204K8-00

$10.49

14

SPACER 1

3XJ-16181-00-00

Unavailable

15

BEARING, CYLINDRICAL(51Y)

93310-225N0-00

$45.99

16

PLATE, THRUST 2

3XJ-16164-00-00

Unavailable

17

WASHER, LOCK(4KB)

90215-16289-00

Unavailable

18

NUT, HEXAGON (30X)

90170-16326-00

Unavailable

19

AXLE, PUSH LEVER

4EX-16382-00-00

Unavailable

20

BOLT (583 TACHOMETER)

90109-06418-00

Unavailable

21

GASKET 256113960000

90430-06014-00

Unavailable

22

OIL SEAL (4G0)

93102-12224-00

Unavailable

23

PUSH LEVER ASSY

3JD-16340-00-00

Unavailable

24

WASHER, PLAIN(735)

90201-10119-00

Unavailable

25

CIRCLIP(10W)

99009-10400-00

Unavailable

26

BRG,CYL-CAL ROLLER 6G TM

93315-11206-00

Unavailable

Yamaha YZ125H1 (YZ125) 4SS2 1996 CLUTCH Diagram

GEAR, PRIMARY DRIVE

COLLAR(2RH)

BOLT, WASHER BASED(1TX)

PRIMARY DRIVEN GEAR COMP.

BOSS, CLUTCH

PLATE, CLUTCH 1

PLATE, FRICTION

PLATE, PRESSURE 1

SPRING (583 CLUTCH)

SCREW, WITH WASHER (1W4)

ROD, PUSH 1

BEARING, THRUST(3AY)

WASHER, PLATE(1HX)

SPACER 1

BEARING, CYLINDRICAL(51Y)

PLATE, THRUST 2

WASHER, LOCK(4KB)

NUT, HEXAGON (30X)

AXLE, PUSH LEVER

BOLT (583 TACHOMETER)

GASKET 256113960000

OIL SEAL (4G0)

PUSH LEVER ASSY

WASHER, PLAIN(735)

CIRCLIP(10W)

BRG,CYL-CAL ROLLER 6G TM
