Yamaha YXZ10YEXKD (YXZ1000R EPS SS) B5H8 2019 SIDE COVER Diagram
#
Description
Price
1
MUD GUARD 1
2HC-F2327-01-00
$56.99
2
DAMPER, PLATE
90520-20007-00
$3.76
3
BOLT, WITH WASHER
90119-06226-00
$8.49
4
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
5
NUT, SPRING
90183-060A6-00
$5.49
6
MUD GUARD
2HC-F2328-01-00
$49.99
7
DAMPER, PLATE
90520-20006-00
$2.55
8
BOLT, WITH WASHER
90119-06226-00
$8.49
9
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
10
NUT, SPRING
90183-060A6-00
$5.49
11
PLATE, UNDER 1
2HC-F84A3-00-00
$59.99
12
NUT, SPRING
90183-060A6-00
$5.49
13
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
14
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
15
PLATE, UNDER 2
2HC-F84A4-00-00
$60.99
16
NUT, SPRING
90183-060A6-00
$5.49
17
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
18
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
19
COVER, SIDE 3
2HC-F1731-00-00
Unavailable
20
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
21
BOLT, WITH WASHER
90119-06226-00
$8.49
22
NUT, SPRING
90183-060A6-00
$5.49
23
COVER, SIDE 4
2HC-F1741-00-00
Unavailable
24
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
25
BOLT, WITH WASHER
90119-06226-00
$8.49
26
NUT, SPRING
90183-060A6-00
$5.49
27
PLATE, UNDER 3
2HC-F84A5-00-00
Unavailable
28
RIVET,SPEC'L SHAPE
90269-07805-00
Unavailable
29
PLATE, RUBBER 1
2HC-F8483-00-00
Unavailable
30
PLATE, RUBBER 2
2HC-F8484-00-00
Unavailable
31
INSULATOR, SIDE CO
B5H-F174A-00-00
Unavailable
