Yamaha YXP1000AT (PRO HAULER 1000) JW52 2005 REAR ARM SUSPENSION Diagram

#

Description
Price

1

REAR ARM COMP.

JN6-F2110-02-00

Unavailable

2

UNDER BRACKET COMP

JU9-F2403-10-00

Unavailable

3

BOLT, FLANGE

95817-10020-00

$4.89

4

BUSH 1

JN6-F2123-20-00

Unavailable

5

BOLT, FLANGE

90105-13800-00

$1.87

6

NUT

90179-13800-00

$1.23

7

BOLT, FLANGE

95817-10020-00

$4.89

8

BOLT 1

JU9-F1631-10-00

Unavailable

9

NUT, SELF-LOCKING(3KJ)

90185-10154-00

$6.22

10

ROD, CONN. ASSY

JN6-F2172-00-00

Unavailable

11

BUSH 2

JN6-F2124-10-00

$4.24

12

BOLT, FLANGE(JN5)

95817-12065-00

$4.48

13

BOLT, FLANGE

9581P-12090-00

Unavailable

14

NUT, SELF-LOCKING

95602-12200-00

$3.56

15

WASHER, PLATE

90201-128S4-00

$1.69

16

SHOCK ABSORBER

JR6-F2210-00-00

$123.15

17

BOLT, FLANGE(JN5)

95817-12065-00

$4.48

18

NUT, SELF LOCKING (1M1)

90185-12072-00

Unavailable

19

COVER, THRUST 1

JN6-F2128-01-00

Unavailable

20

RIVET, BLIND

90267-48850-00

Unavailable

21

RIVET, BLIND

90267-40851-00

Unavailable

22

SUPT. BRKT. ASSY.

JU9-F5920-01-00

Unavailable

23

BOLT, FLANGE(JN5)

95817-12065-00

$4.48

24

NUT, SELF LOCKING (1M1)

90185-12072-00

Unavailable

25

BRKT., ROD PLATE 2

JU9-F253H-00-00

Unavailable

26

BOLT, FLANGE

9581P-12025-00

Unavailable

27

NUT, SELF-LOCKING

95602-12200-00

$3.56
