Yamaha YXF85WPAJL (WOLVERINE X4) BG46 2018 FRONT BRAKE CALIPER Diagram

#

Description
Price

1

DISC, BRAKE (LEFT)

2MB-F582T-00-00

Unavailable

2

BOLT

90109-08077-00

$8.49

3

DISC, BRAKE (LEFT)

2MB-F582T-00-00

Unavailable

4

BOLT

90109-08077-00

$8.49

5

BOLT

90101-10045-00

$2.55

6

WASHER, PLATE

90201-10033-00

$8.49

7

CALIPER ASSY (LEFT)

1XD-2580T-00-00

$427.99

8

PISTON ASSY, CALIPER

1XD-25802-00-00

$44.99

9

CALIPER SEAL KIT

1XD-25803-00-00

$42.99

10

BOOT 2

1UY-25937-51-00

$14.49

11

BOOT, CALIPER

3JD-25917-00-00

$8.99

12

SUPPORT, PAD

1XD-25919-00-00

$13.49

13

BLEED SCREW KIT

36Y-W0048-00-00

$9.99

14

BOLT

1UY-25926-51-00

$4.47

15

WASHER, SPRING

1UY-25938-51-00

Unavailable

16

BOLT

3JD-25926-00-00

Unavailable

17

NUT

3JD-25961-00-00

Unavailable

18

BRAKE PAD KIT

1XD-25805-00-00

Unavailable

19

PIN, PAD

3TB-25933-00-00

Unavailable

20

CALIPER ASSY (RIGHT)

1XD-2580U-00-00

Unavailable

21

PISTON ASSY, CALIPER

1XD-25802-00-00

$44.99

22

CALIPER SEAL KIT

1XD-25803-00-00

$42.99

23

BOOT 2

1UY-25937-51-00

$14.49

24

BOOT, CALIPER

3JD-25917-00-00

$8.99

25

SUPPORT, PAD

1XD-25919-00-00

$13.49

26

BLEED SCREW KIT

36Y-W0048-00-00

$9.99

27

BOLT

1UY-25926-51-00

$4.47

28

WASHER, SPRING

1UY-25938-51-00

Unavailable

29

BOLT

3JD-25926-00-00

Unavailable

30

NUT

3JD-25961-00-00

Unavailable

31

BRAKE PAD KIT

1XD-25805-10-00

Unavailable

32

PIN, PAD

3TB-25933-00-00

Unavailable
