Yamaha YT125K 1983 REAR BRAKE CALIPER Diagram

#

Description
Price

1

DISC, BRAKE

5V6-25711-00-00

Unavailable

2

BODY, CALIPER 1

5V6-25731-00-00

Unavailable

3

BODY, CALIPER 2

5V6-25741-00-00

Unavailable

4

BRAKE PAD KIT

2HR-W0045-09-00

$44.99

5

CAM

20E-25728-00-00

$20.99

6

BOLT, HEAD WITH HOLE(71G)

90103-08026-00

$11.49

7

NUT(6L2)

95333-08600-00

$2.49

8

WASHER, PLATE (12X)

90201-087F0-00

$5.60

9

LEVER, BRAKE

20E-25726-00-00

Unavailable

10

PLATE, BACK UP

J45-25733-00-00

Unavailable

11

OIL SEAL (3X3)

93102-15212-00

$9.49

12

BOLT

90101-10452-00

Unavailable

13

WASHER, PLATE

92990-10600-00

Unavailable

14

NUT, U

95617-10100-00

$8.49

15

SPRING, TENSION(4GB)

90506-16482-00

$8.49

16

COVER 1

20E-25715-00-00

Unavailable

17

COVER 2

20E-25716-00-00

Unavailable

18

SCREW PAN HEAD

98580-06010-00

Unavailable

19

WASHER, SPRING

92995-06100-00

Unavailable

20

UNAVAILABLE IN PRICE BOOK (92502-06016-00)

92503-06016-00

Unavailable

21

WASHER, SPRING

92995-06100-00

Unavailable

22

COLLAR

(90387-074G5-00)

Unavailable

23

WASHER, PLATE

90201-096F7-00

Unavailable

24

WASHER, PLATE

90201-06049-00

Unavailable
