Description

Price

1

DISC, BRAKE

5V6-25711-00-00

Unavailable

2

BODY, CALIPER 1

5V6-25731-00-00

Unavailable

3

BODY, CALIPER 2

5V6-25741-00-00

Unavailable

4

BRAKE PAD KIT

2HR-W0045-09-00

$44.99

5

CAM

3X3-25728-00-00

Unavailable

6

BOLT, HEAD WITH HOLE(71G)

90103-08026-00

$11.49

7

NUT(6L2)

95333-08600-00

$2.49

8

WASHER, PLATE (12X)

90201-087F0-00

$5.60

9

LEVER, BRAKE

3X3-25726-01-00

Unavailable

10

HOOK, SPRING

3X3-25736-00-00

Unavailable

11

PLATE, BACK UP

J45-25733-00-00

Unavailable

12

OIL SEAL (3X3)

93102-15212-00

$9.49

13

BOLT, HEXAGON

97017-10085-00

Unavailable

14

WASHER, PLATE

92990-10600-00

Unavailable

15

YBS67-10 WASHER, SPRING

92990-10100-00

$7.49

16

NUT(624)

95380-10600-00

Unavailable

17

SPRING, TENSION (3X3)

90506-16215-00

Unavailable

18

COVER 1

5V6-25715-00-00

Unavailable

19

COVER 2

5V6-25716-00-00

Unavailable

20

RIVET, SPEC''L SHAPE

90269-06026-00

Unavailable

21

SCREW, PAN

98507-06014-00

Unavailable

22

WASHER, SPRING

92995-06100-00

Unavailable

23

WASHER, PLAIN (646)

92990-06600-00

Unavailable

Yamaha YT125G 1980 REAR BRAKE CALIPER YT125J Diagram

DISC, BRAKE

BODY, CALIPER 1

BODY, CALIPER 2

BRAKE PAD KIT

CAM

BOLT, HEAD WITH HOLE(71G)

NUT(6L2)

WASHER, PLATE (12X)

LEVER, BRAKE

HOOK, SPRING

PLATE, BACK UP

OIL SEAL (3X3)

BOLT, HEXAGON

WASHER, PLATE

YBS67-10 WASHER, SPRING

NUT(624)

SPRING, TENSION (3X3)

COVER 1

COVER 2

RIVET, SPEC''L SHAPE

SCREW, PAN

WASHER, SPRING

WASHER, PLAIN (646)
