Yamaha YL1 (YL1_1E) 1966 REAR ARM AND CHAIN CASE Diagram

#

Description
Price

1

RR FOOTREST ASSEMBLY 1

120-27430-01-00

Unavailable

2

SEAL,GUARD

296-22151-01-00

Unavailable

3

BUSH 1

102-22123-00-00

Unavailable

4

SHAFT, PIVOT

486-22141-01-00

$33.99

5

NUT, SELF LOCKING

90185-10031-00

Unavailable

6

CAP, REAR ARM

180-22117-00-00

$7.99

7

WASHER, PLATE (4N0)

90201-126A7-00

$9.49

8

NUT, CROWN

90176-12006-00

Unavailable

9

REAR FOOTREST ASSY

120-27430-00-00

Unavailable

10

COVER, REAR FOOTREST

120-27433-00-00

$8.99

11

NUT, HEXAGON

90170-12061-00

Unavailable

12

CASE, CHAIN

128-22311-00-35

Unavailable

13

YBS67-5 WASHER, SPRING

92990-05100-00

$0.35

14

SCREW, PAN HEAD

92501-05006-00

Unavailable

15

SCREW, PAN HEAD(4MY)

98507-05018-00

$3.28

16

YBS67-10 WASHER, SPRING

92990-10100-00

Unavailable

17

BOLT(8BT)

97017-10020-00

Unavailable
