Yamaha YFZ450SP2X (YFZ450 SPECIAL EDITION II) 5D3J 2008 REAR FENDER FOOTWELLS Diagram

#

Description
Price

1

REAR FENDER COMP.

5TG-W2161-72-00

Unavailable

2

BOLT, FLANGE

90105-06084-00

$4.61

3

COLLAR

90387-06146-00

$8.49

4

BOLT, FLANGE

90105-06084-00

$4.61

5

WASHER, PLATE

90201-06087-00

$3.35

6

STAY, REAR

5TG-21643-10-00

$34.99

7

BOLT, FLANGE

95817-08012-00

$5.49

8

STAY, REAR

5TG-21644-20-00

$35.99

9

BOLT, BUTTON HEAD

92012-08012-00

$8.49

10

BOLT

90111-06038-00

$4.29

11

NUT, U FLANGE

95604-06200-00

$8.49

12

COVER, REAR FENDER 1

5TG-2163A-01-00

$16.49

13

COVER, REAR FENDER 2

5TG-2163E-10-00

$7.99

14

COVER, REAR FENDER 3

5TG-2163F-10-00

$3.33

15

DAMPER 2

5TG-21639-00-00

$7.99

16

FOOTWELL KIT

GYT-5TG57-00-BK

Unavailable

17

PLASTIC FOOT EX- RAPTOR 700

ATV-1AS57-00-01

Unavailable
