Description

Price

1

WHEEL COMP.

5LP-25180-11-YX

Unavailable

2

TIRE (AT21X7R10 KT331A TL)

94107-10011-00

Unavailable

3

VALVE, RIM(2GH)

93900-00030-00

$16.99

4

WHEEL COMP.

5LP-25180-11-YX

Unavailable

5

TIRE (AT21X7R10 KT331A TL)

94107-10011-00

Unavailable

6

VALVE, RIM(2GH)

93900-00030-00

$16.99

7

HUB, FRONT

5LP-25111-00-00

$224.99

8

BOLT (38W)

90114-10007-00

$5.60

9

SPACER, BEARING

5LP-25117-00-00

$17.49

10

BEARING(3BN)

93306-00438-00

$37.99

10

BEARING(3BN)

93306-00438-00

$37.99

11

BRG,R-B 6202Z 35MM 48G NT

93306-20204-00

$22.99

12

OIL SEAL(1UY)

93105-26026-00

$12.49

13

OIL SEAL (7H5)

93102-22216-00

$11.49

14

NUT, FLANGE(8AB)

95707-10500-00

$3.18

15

WASHER, PLAIN(3BM)

92907-10200-00

Unavailable

16

COVER, PLATE

3GD-25127-10-00

Unavailable

Yamaha YFZ450S (YFZ450) 5TG1 2004 FRONT WHEEL Diagram

WHEEL COMP.

TIRE (AT21X7R10 KT331A TL)

VALVE, RIM(2GH)

WHEEL COMP.

TIRE (AT21X7R10 KT331A TL)

VALVE, RIM(2GH)

HUB, FRONT

BOLT (38W)

SPACER, BEARING

BEARING(3BN)

BEARING(3BN)

BRG,R-B 6202Z 35MM 48G NT

OIL SEAL(1UY)

OIL SEAL (7H5)

NUT, FLANGE(8AB)

WASHER, PLAIN(3BM)

COVER, PLATE
