Yamaha YFZ450RSEZ (YFZ450R SPECIAL EDITION) 18PA 2010 REAR FENDER Diagram
#
Description
Price
2
PROTECTOR,1
18P-2476U-00-00
Unavailable
3
PROTECTOR,2
18P-2476V-00-00
Unavailable
14
PROTECTOR
18P-21652-00-00
Unavailable
16
COVER, REAR FENDER 3
18P-2163F-00-00
Unavailable
17
FLAP
18P-21621-00-00
Unavailable
18
STAY 1
18P-2164F-00-00
Unavailable
19
STAY 3
18P-2164H-00-00
Unavailable
20
SCREW, BINDING (10V)
90154-05013-00
Unavailable
21
BOLT, BUTTON HEAD
92012-06030-00
Unavailable
22
COLLAR
90387-06205-00
Unavailable
23
NUT, U FLANGE
95604-06200-00
Unavailable
24
WASHER, PLATE
90201-06380-00
Unavailable
25
FLAP
18P-21691-00-00
Unavailable
26
STAY 2
18P-2164G-00-00
Unavailable
27
STAY 4
18P-2164J-00-00
Unavailable
28
SCREW, BINDING (10V)
90154-05013-00
Unavailable
29
BOLT, BUTTON HEAD
92012-06030-00
Unavailable
30
COLLAR
90387-06205-00
Unavailable
31
NUT, U FLANGE
95604-06200-00
Unavailable
32
WASHER, PLATE
90201-06380-00
Unavailable
33
BOLT, FLANGE(4LN)
95817-08025-00
Unavailable
34
WASHER, PLATE
90201-08048-00
Unavailable
35
NUT, SELF-LOCKING
95602-08200-00
Unavailable
36
BOLT, BUTTON HEAD
92012-08020-00
Unavailable
37
WASHER, PLATE
90201-08043-00
Unavailable
38
COVER, REAR FENDER 1
18P-2163A-00-00
Unavailable
39
BOLT
90109-06249-00
Unavailable
