Yamaha YFZ350R (BANSHEE) 5FKJ 2003 FUEL TANK Diagram

#

Description
Price

1

FUEL TANK COMP.

2GU-24110-00-00

Unavailable

2

CAP ASSY

5KM-24610-00-00

$49.64

3

FUEL COCK ASSY 1

2GU-24500-02-00

$50.01

4

SEAL, COCK

3AJ-24534-01-00

$8.69

5

SCREW, PAN HEAD (J10)

98580-03008-00

$2.14

6

O-RING

4X8-24512-00-00

$6.25

7

VALVE PACKING

3AC-24523-00-00

$10.82

8

WASHER, PLATE(3MB)

90202-05187-00

$1.01

9

SCREW 256241430000

90149-06011-00

$1.56

10

GROMMET (4V1)

90480-18290-00

$6.54

11

COLLAR (36R)

90387-066J1-00

$6.39

12

BOLT, HEXAGON

97017-06030-00

$2.80

13

WASHER, SPRING

92907-06100-00

$0.98

14

GROMMET(38W)

90480-01400-00

$9.40

15

WASHER, PLATE

90201-06090-00

$4.82

16

COLLAR (1T2)

90387-07598-00

Unavailable

17

BOLT, HEXAGON

97017-06030-00

$2.80

18

WASHER, SPRING

92907-06100-00

$0.98

19

HOSE (L166)

90445-13693-00

Unavailable

20

CLIP(1JH)

90467-11106-00

Unavailable

21

HOSE (L600)

90445-083J5-00

Unavailable
