Yamaha YFZ350B_MNH (BANSHEE) 1991 (TAILLIGHT KIT) MAINE AND NEW HAMPSHIRE ONLY Diagram

#

Description
Price

1

MASTER CYLINDER SUB ASSY

2GU-25870-10-00

$294.99

2

PEDAL, BRAKE

3GG-27211-10-00

$55.99

3

TAILLIGHT UNIT ASSEMBLY

3JM-84710-00-00

Unavailable

4

LENS, TAILLIGHT

21V-84721-00-00

$33.99

5

BULB, TAIL LAMP (12V 32/3CP)

256-84714-61-00

$11.99

6

GASKET, TAIL LENS

1K8-84523-00-00

Unavailable

7

YBS83-430 SCREW,PANH. TAPPING

97780-40130-00

$8.49

8

BRACKET, TAILLIGHT

3GD-84702-10-00

Unavailable

9

WASHER, PLATE (462)

90202-14077-00

$4.29

10

GROMMET

90480-10509-00

Unavailable

11

COLLAR

90387-06387-00

Unavailable

12

WASHER PLATE 248217570000

90201-06074-00

$9.49

13

NUT, HEXAGON

95380-06600-00

Unavailable

14

WASHER, SPRING

92995-06100-00

Unavailable

15

BOLT, FLANGE

95822-06025-00

$1.75

16

GROMMET 839774310000

90480-14023-00

Unavailable

17

COLLAR

90387-06158-00

Unavailable

18

WIRE, SUB-LEAD

3GG-82509-00-00

Unavailable

19

SWITCH, HANDLE 2

3GG-83975-00-00

Unavailable

20

FRONT STOP SWITCH ASSEMBLY

3GD-83980-00-00

Unavailable

21

STOP SWITCH ASSY

3GG-82530-02-00

Unavailable

22

STAY, STOP SWITCH

3GG-2144G-00-00

Unavailable

23

BOLT, BUTTON HEAD(3JP)

92014-06012-00

Unavailable

24

NUT,SELF-LOCKING

95607-06200-00

Unavailable

25

GUIDE

3GG-15377-00-00

Unavailable

26

BAND, SWITCH CORD

437-83936-01-00

Unavailable

27

BAND, SWITCH CORD

437-83936-11-00

Unavailable

32

YFZ350 TAIL LGHTKT

3GG-W8472-00-00

Unavailable
