Yamaha YFS200J (BLASTER) 3JMN 1997 REAR WHEEL Diagram

#

Description
Price

1

COLLAR, WHEEL

2XJ-25383-50-00

Unavailable

2

REAR WHEEL COMP.

2VY-25390-00-35

Unavailable

3

TIRE (AT21X10-8*KT895A T/L N)

94110-085W9-00

Unavailable

4

VALVE, RIM(2GH)

93900-00030-00

$16.99

5

NUT, FLANGE(8AB)

95707-10500-00

$3.18

6

WASHER, PLATE

90201-14022-00

$5.60

7

NUT, CASTLE (29U)

90171-14037-00

$11.49

8

PIN, COTTER

91490-30030-00

$8.49

9

AXLE, WHEEL

2XJ-25381-00-00

Unavailable

10

COLLAR, SPROCKET AXLE

2XJ-25386-00-00

$201.99

11

BOLT, STUD(2XJ)

90116-08507-00

$9.49

12

SPROCKET, DRIVEN (40T)

2XJ-25440-21-00

$42.99

13

WASHER

2XJ-25412-00-00

$4.32

14

NUT (3Y2)

90170-08258-00

$3.50

15

HUB, REAR

2XJ-25311-00-35

Unavailable

16

SPACER, BEARING

2XJ-25317-00-00

Unavailable

17

BEARING(38W)

93306-00705-00

Unavailable

18

OIL SEAL(3BC)

93106-42026-00

Unavailable

19

COLLAR(2XJ)

90387-561U7-00

Unavailable

20

PULLER, CHAIN 1

2XJ-25388-00-00

Unavailable

21

BOLT(4SR)

90101-08777-00

Unavailable

22

NUT(6TA)

95337-08600-00

Unavailable

23

CHAIN

9Y581-87091-00

Unavailable

24

JOINT, CHAIN

94681-87011-00

Unavailable

25

BOLT(2XJ)

90101-10678-00

Unavailable

26

WASHER, PLATE (17K)

90201-106F2-00

Unavailable

27

BOLT(2XJ)

90101-10678-00

Unavailable

28

WASHER, PLATE (17K)

90201-106F2-00

Unavailable

29

NUT, FLANGE(8AB)

95707-10500-00

$3.18

30

NUT

90170-33011-00

Unavailable
