Yamaha YFM70KDXHG (KODIAK 700 4WD) B16A 2017 RADIATOR HOSE Diagram

#

Description
Price

1

THERMOSTAT

2MB-E2411-00-00

$78.40

2

COVER, THERMOSTAT

B16-E2413-00-00

$34.40

3

GASKET

2MB-E2435-00-00

$2.09

4

BOLT 1

2MB-E5481-60-00

$0.94

5

BOLT 1

2MB-E5481-10-00

$1.02

6

HOSE 1

B16-E2576-00-00

$28.94

7

CLIP

90467-26189-00

$5.86

8

HOSE CLAMP ASSY

90450-32015-00

$15.23

9

HOSE 3

B16-E2578-00-00

$20.23

10

CLIP

90467-26189-00

$5.86

11

RADIATOR ASSY

B16-E2460-02-00

Unavailable

12

BLOWER ASSY

B16-E2405-01-00

$175.77

13

. NUT SPRING

1HP-E2535-00-00

$4.85

14

BOLT, BLOWER HOLDING

1HP-E2675-00-00

$3.94

15

CAP, RADIATOR

1XD-E2462-00-00

Unavailable

16

GROMMET(2GH)

90480-12475-00

$6.68

17

BOLT, FLANGE

95817-06020-00

$2.69

18

WASHER

90209-06012-00

$4.71

19

COLLAR

90387-06113-00

$10.51
