Yamaha YFM4AS (KODIAK 400 2WD) 5VH5 2004 SIDE COVER Diagram

#

Description
Price

1

TANK, RECOVERY

5ND-F1871-00-00

Unavailable

2

CAP

1AA-21815-00-00

$11.09

3

GASKET

1AA-21874-00-00

$6.38

4

HOSE

90445-08811-00

$5.49

5

HOSE

90445-08812-00

$6.25

6

BOLT, WITH WASHER

90119-06226-00

$2.15

7

CLIP 101235600

90467-08003-00

$6.13

8

COVER, TOP

5ND-F171A-01-00

$129.83

8

COVER, TOP

5ND-F171A-11-00

$146.99

8

COVER, TOP

5ND-F171A-51-00

$129.66

9

CLOTH, PROTECTOR

5ND-F174M-00-00

Unavailable

10

BOLT,HEX. SOCKET BUTTON

90111-05059-00

$2.15

11

GROMMET(4FU)

90480-13567-00

$3.88

12

NUT, SPRING

90183-051A0-00

$2.66

13

BOLT, WITH WASHER (25K)

90119-06079-00

$0.97

14

COVER, SIDE 1

5ND-F1711-00-00

Unavailable

15

INSULATOR,SIDE CVR

5ND-F174A-01-00

$7.94

16

COVER, SIDE 2

5ND-F1721-00-00

Unavailable

17

INSULATOR, SIDE COVER

5ND-F174T-01-00

$26.45
