Yamaha YFM4AS (KODIAK 400 2WD) 5VH5 2004 METER Diagram

#

Description
Price

1

HOUSING, TACHOMETER GEAR

4WV-17811-00-00

$91.31

2

BUSH (214-17843-00)

90381-08002-00

$10.54

3

GEAR, DRIVE

4WV-17831-00-00

$41.95

4

GEAR, DRIVEN

4WV-17841-00-00

$40.37

5

O-RING(59V)

93210-24253-00

$4.84

6

HOUSING, TACHOMETER GEAR

59V-17811-00-00

$51.40

7

SCREW, PAN HEAD(3TJ)

98507-06016-00

$2.43

8

O-RING (341)

93210-32172-00

$5.78

9

WASHER (692)

90201-12M34-00

$3.47

10

OIL SEAL (30X)

93102-08307-00

$4.11

11

BOLT,SOCKET

91317-06020-00

$2.11

12

SCREW, PAN

98517-06030-00

$3.38

13

. SPEEDOMETER ASSY

5GH-83500-00-00

Unavailable

14

.. KNOB, TRIP METER

3GH-83578-00-00

Unavailable

15

DAMPER

3GH-83523-00-00

Unavailable

16

.. SOCKET CORD ASSY

5GH-83520-00-00

Unavailable

17

BULB (T6.5 12V-3W)

42X-83517-00-00

$6.48

18

NUT, FLANGE(3GM)

95707-05500-00

$6.18

19

WASHER, PLATE (8J0)

90201-05725-00

$6.80

20

BRACKET, METER

5TE-H3519-00-00

Unavailable

21

RIVET

90269-06800-00

$1.45

22

SPEEDOMETER CABLE

5VH-H3550-01-00

$10.68

23

O-RING (26H)

93210-14579-00

$5.69
