Yamaha YFM350FWBKC (BIG BEAR 4WD) 4WU50 1998 FRONT SUSPENSION WHEEL Diagram

FRONT UPPER ARM COMP. (LEFT)

4WU-23540-00-00

Unavailable

FRONT UPPER ARM COMP. (RIGHT)

4WU-23550-00-00

$193.99

NUT, CASTLE

90171-10001-00

$7.49

PIN, COTTER

91490-20025-00

$1.99

FRONT LOWER ARM COMP. (LEFT)

4KB-23570-11-00

Unavailable

BOLT, FLANGE (2XJ)

90105-10549-00

$7.49

NUT(6TD)

95337-10600-00

$9.49

WASHER (7A9)

90201-100F7-00

$9.49

BUSH

2HR-23526-00-00

$20.99

BOLT, WASHER BASED(4EB)

90105-10788-00

$28.99

NUT, SELFLOCKING (533 FRAME)

90185-10060-00

$7.49

SHOCK ABSORBER ASSY

4WU-23350-01-00

Unavailable

BOLT, WASHER BASED(59V)

90105-10388-00

$10.49

NUT, SELFLOCKING (533 FRAME)

90185-10060-00

$7.49
