Yamaha YFM350FWBJ_MNH (BIG BEAR 4WD) 4WU1 1997 TAILLIGHT KIT Diagram
#
Description
Price
2
CYLINDER KIT, MASTER
4H7-W0041-50-00
Unavailable
7
WASHER, PLATE(481)
90201-10118-00
Unavailable
8
PEDAL, BRAKE
4WU-27211-10-00
Unavailable
9
WIRE, SUB-LEAD
4WU-82509-00-00
Unavailable
10
FRONT STOP SWITCH ASSEMBLY
3HN-83973-10-00
Unavailable
11
SWITCH, HANDLE 3
4GB-83973-10-00
Unavailable
12
STOP SWITCH ASSEMBLY
4KB-82530-00-00
Unavailable
13
FRONT STOP SWITCH ASSEMBLY
3GD-83980-00-00
Unavailable
14
BRACKET, STOP SWITCH
4KB-21441-00-00
Unavailable
16
BAND, SWITCH CORD
437-83936-01-00
Unavailable
17
CLAMP
90465-10098-00
Unavailable
18
BAND, SWITCH CORD
437-83936-11-00
Unavailable
19
TAILLIGHT UNIT ASSEMBLY
3HN-84710-20-00
Unavailable
20
BULB, TAIL LAMP (12V 32/3CP)
256-84714-61-00
Unavailable
21
GASKET, TAIL LENS
1K8-84523-00-00
Unavailable
22
LENS, TAILLIGHT
21V-84721-00-00
Unavailable
23
YBS83-430 SCREW,PANH. TAPPING
97780-40130-00
Unavailable
