Yamaha YFM125S (GRIZZLY 125) 1C51 2004 CRANKCASE Diagram

#

Description
Price

1

CRANKCASE ASSY

3FA-15100-00-00

$813.99

2

PIPE, BREATHER 2

59V-11167-00-00

$10.31

3

PIN, DOWEL

99530-12016-00

$4.12

4

HOSE (L700)

90445-121F6-00

$10.82

5

CLIP(3YX)

90467-13133-00

$5.13

6

SCREW, PAN

98517-06030-00

$3.38

7

SCREW, PAN

98507-06040-00

$2.25

8

SCREW, PAN

98507-06060-00

$5.60

9

SCREW, PAN HEAD

98507-06070-00

$6.91

10

CLAMP(4MX)

90465-06376-00

$7.08

11

SCREW, PAN HEAD(3FA)

98507-08012-00

$1.32

12

WASHER, PLATE 3411117500

90201-08087-00

$3.13

13

GASKET, CRANKCASE COVER 3

3FA-15462-10-00

$12.26

14

COVER, CHAIN CASE

50M-15418-00-00

Unavailable

15

OIL SEAL(50M)

93102-22294-00

$11.80

16

PIN, DOWEL (4N0)

93605-18078-00

Unavailable

17

O-RING(2YM)

93210-704A7-00

$4.54

18

SCREW, FLAT HEAD(4EM)

98707-06016-00

$6.68

19

O-RING (11M)

93210-07540-00

$5.77

20

GASKET

214-11198-01-00

$2.66

21

PLUG, STRAIGHT SCREW(3FA)

90340-14132-00

$2.65

22

GASKET 256131670000

90430-14043-00

$6.46

23

PLUG, (663)

90340-14036-00

$12.75

24

GROMMET (462)

90480-13018-00

$6.25

25

ADAPTOR

3FA-15787-00-00

$113.52

26

GASKET, CRANKCASE COVER 2

3FA-15461-10-00

$19.03

27

PIN, DOWEL(3VD)

99530-10114-00

$2.23

28

SCREW, PAN

98517-06030-00

$3.38

29

SCREW, PAN

98507-06040-00

$2.25

30

CLAMP(4MX)

90465-06376-00

$7.08

31

PLUG, STRAIGHT SCREW(2HT)

90340-14117-00

$11.62

32

O-RING (2H9)

93210-14369-00

$5.80

33

PLUG, STRAIGHT SCREW (5Y1)

90340-36078-00

$12.34

34

O-RING

93210-35804-00

$0.49
