Yamaha YFB250FWF (TIMBERWOLF 4WD) 4KD1 1994 DRIVE SHAFT Diagram

#

Description
Price

1

REAR AXLE GEAR CASE ASSY

4BD-46101-10-00

Unavailable

2

. HOUSING, DRIVE SHAFT

2VY-46151-01-00

Unavailable

3

BOLT, STUD(2GG)

95617-08620-00

$7.49

4

. BEARING ASSY

24W-46102-00-00

Unavailable

5

OIL SEAL (24W)

93101-52116-00

$16.99

6

BEARING, CYLINDRICAL(3HN)

93317-85569-00

$86.99

7

RING GEAR SET

4BD-Y4612-10-00

$417.99

8

SHIM, THRUST (0.30T)

1J7-17537-Y0-30

$4.47

8

SHIM, THRUST (0.40T)

1J7-17537-Y0-40

$4.47

8

SHIM, THRUST (0.50T)

1J7-17537-Y0-50

$4.47

9

BEARING(3RR)

93306-30560-00

Unavailable

10

RETAINER, BEARING

29U-46125-00-00

$92.99

11

COLLAR (24W)

90387-255H9-00

Unavailable

12

WASHER, THRUST

24W-46118-00-12

Unavailable

12

WASHER, THRUST

24W-46118-00-14

$16.49

12

WASHER, THRUST

24W-46118-00-16

Unavailable

12

WASHER, THRUST

24W-46118-00-18

Unavailable

12

WASHER, THRUST

24W-46118-00-20

Unavailable

13

PLUG, STRAIGHT SCREW

90340-14002-00

Unavailable

14

GASKET

214-11198-01-00

Unavailable

15

BREATHER

2H7-17591-01-00

Unavailable

16

. SHIM, RING GEAR (025T)

24W-46117-00-25

Unavailable

16

. SHIM, RING GEAR (030T)

24W-46117-00-30

Unavailable

16

. SHIM, RING GEAR (040T)

24W-46117-00-40

Unavailable

16

. SHIM, RING GEAR (050T)

24W-46117-00-50

Unavailable

17

BEARING, CYLINDRICAL (22U)

93316-01301-00

Unavailable

18

OIL SEAL (22U)

93102-65277-00

Unavailable

19

O-RING (1J7)

93211-44348-00

Unavailable

20

BOLT (682)

97013-08025-00

Unavailable

21

.. WASHER, PLATE

92990-08600-00

Unavailable

22

BOLT(6TD)

97017-10025-00

Unavailable

23

WASHER, PLATE

92990-10600-00

Unavailable

24

. HOUSING, BEARING

3GC-46152-00-00

Unavailable

25

O-RING (11H)

93210-59531-00

Unavailable

26

OIL SEAL (4H7)

93101-38098-00

Unavailable

27

NUT(55X)

90179-08491-00

Unavailable

28

WASHER, PLATE(3XP)

90201-086P8-00

Unavailable

29

O-RING (173)

93210-85075-00

Unavailable

30

BOLT, FLANGE(3GD)

95817-10025-00

Unavailable

31

WASHER, PLATE(47X)

90201-101J1-00

Unavailable

32

COUPLING, GEAR

2HR-46123-00-00

Unavailable

33

SHAFT, DRIVE

4BD-46172-00-00

Unavailable

34

CIRCLIP (537)

93410-22039-00

Unavailable

35

CROSS JOINT COMP.

4X7-46180-00-00

Unavailable

36

BEARING(2HR)

93399-99926-00

Unavailable

37

CIRCLIP (4X7)

93440-20088-00

Unavailable

38

CLIP (1J7)

90467-07029-00

Unavailable

39

HOSE (L1050)

90445-072G8-00

Unavailable
