Yamaha XVZ13ATLC (ROYAL STAR TOUR CLASSIC CA) 5EJ6 1999 FENDER Diagram
#
1
FRONT FENDER ASSEMBLY (BRIGHT CHERRY RED)
4NK-Y2150-90-4X
Unavailable
1
FRONT FENDER ASSY (YAMAHA BLACK)
4NK-Y2150-F0-33
Unavailable
2
. GRAPHIC SET, FRONT FENDER (BRIGHT CHERRY RED)
4NK-21570-50-00
Unavailable
2
. GRAPHIC SET, FRONT FENDER (YAMAHA BLACK)
4YP-21570-00-00
Unavailable
4
EMBLEM 3
4NL-2152A-10-00
Unavailable
5
EMBLEM
4NL-21578-10-00
Unavailable
6
REAR FENDER C0MP. (YAMAHA BLACK)
5EJ-Y2161-20-33
Unavailable
6
REAR FENDER C0MP. (BRIGHT CHERRY RED) (CARMINE RED)
5EJ-Y2161-30-2X
Unavailable
7
. GRAPHIC SET, REAR FENDER (BRIGHT CHERRY RED)
4NK-2165A-50-00
Unavailable
7
. GRAPHIC SET, REAR FENDER (YAMAHA BLACK)
4YP-2165A-00-00
Unavailable
11
DAMPER
4NK-21649-00-00
Unavailable
12
GROMMET (438)
90480-15061-00
Unavailable
13
FLAP (YAMAHA BLACK) (MILKY BROWN)
4NK-21621-00-33
Unavailable
13
FLAP (BRIGHT CHERRY RED)
4NK-21621-00-E9
Unavailable
14
NUT, SPRING(4ES)
90183-06069-00
Unavailable
15
BOLT, HEXAGON SOCKET HEAD(3HE)
90110-06200-00
Unavailable
16
WASHER, PLATE
90202-06170-00
Unavailable
17
PLUG, BLIND
4NK-83345-00-00
Unavailable
18
STAY, 9
4YE-2317W-00-00
Unavailable
19
BOLT, BUTTON HEAD(3JP)
92014-06012-00
Unavailable
20
WASHER, PLATE 6261117600
90201-06043-00
Unavailable
21
BRACKET, REFLECTOR
4NK-21641-00-00
Unavailable
22
BOLT, FLANGE(2UJ)
95024-06010-00
Unavailable
23
REAR REFLECTOR ASSY
8Y7-85130-00-00
Unavailable
24
NUT, FLANGE(3GM)
95707-05500-00
Unavailable
25
HOSE (583)
90446-07114-00
Unavailable
26
DAMPER 2
5A8-21639-00-00
Unavailable
27
BRACKET, SEAT LEVER 1
4NK-2475H-00-00
Unavailable
28
0DAMPER, SEAT
95092-47240-00
Unavailable
29
BOLT, FLANGE(4MY)
95027-06012-00
Unavailable
