Yamaha XVZ1300TFSMC (ROYAL STAR VENTURE MM CA) 5MC2 2000 RADIATOR HOSE Diagram

#

Description
Price

1

HOSE 3 (L81.8)

4XY-12578-00-00

Unavailable

2

HOSE CLAMP ASSY

90450-28001-00

$14.99

3

RADIATOR ASSY

4XY-12461-00-00

Unavailable

4

BLOWER ASSY

4XY-12405-00-00

Unavailable

5

PLUG,DRAIN COCK

1AA-12561-00-00

$28.99

6

GASKET

1AA-12435-00-00

$8.99

7

BOLT, WITH WASHER

90119-06242-00

$7.49

8

DAMPER, RADIATOR

4XY-12465-00-00

Unavailable

9

COLLAR

90387-0614X-00

Unavailable

10

GROMMET (4L0)

90480-19283-00

$8.49

11

BOLT, FLANGE

95817-06045-00

$8.49

12

GROMMET

90480-16284-00

$11.49

13

HOSE (L1500)

90445-090F6-00

$31.99

14

CLIP 101235600

90467-08003-00

$10.49

15

CLAMP

90464-25267-00

$7.49

16

HOSE 1

4XY-12576-00-00

Unavailable

17

CLIP (10V)

90467-23067-00

Unavailable

18

HOSE CLAMP ASSY

90450-28001-00

$14.99

19

PIPE 5

4XY-12485-00-00

Unavailable

20

O-RING (716)

93210-18417-00

Unavailable

21

BOLT,SOCKET

91317-06012-00

Unavailable

22

HOSE 4 (L85)

4XY-12579-00-00

Unavailable

23

HOSE CLAMP ASSY(3GM)

90450-38040-00

Unavailable

24

HOSE 2

4XY-12577-00-00

Unavailable

25

CLIP (10V)

90467-23067-00

Unavailable

26

COVER 1

26H-1246A-03-00

Unavailable

27

COVER 2

26H-1246E-03-00

Unavailable

28

GASKET, HOUSING COVER 2

26H-12428-00-00

Unavailable

29

BOLT, SOCKET

91314-06016-00

Unavailable

30

GASKET, HOUSING COVER 1

26H-12427-00-00

Unavailable

31

PIPE, BREATHER 1

4XY-11166-00-00

Unavailable

32

CLIP (371)

90467-14015-00

Unavailable

33

BOLT, SOCKET

91314-06040-00

Unavailable

34

BOLT, SOCKET

91314-06040-00

Unavailable

35

HOSE 6

4XY-12589-00-00

Unavailable

36

HOSE CLAMP ASSY

90450-28001-00

$14.99

37

PIPE 4

4XY-12484-00-00

Unavailable

38

O-RING (716)

93210-18417-00

Unavailable

39

BOLT,SOCKET

91317-06012-00

Unavailable

40

HOSE 5

4XY-12588-00-00

Unavailable

41

HOSE CLAMP ASSY(3GM)

90450-38040-00

Unavailable

42

HOSE 7

4XY-12551-00-00

Unavailable

43

CLIP(3BM)

90467-10135-00

Unavailable

44

BOLT, FLANGE

95817-06012-00

Unavailable

45

PIPE 1

4XY-12481-00-00

Unavailable

46

BOLT

97027-05010-00

Unavailable

47

WASHER(1RW)

92907-05600-00

Unavailable

48

CONDUCTION ASSY

4NK-12590-00-00

Unavailable

49

CAP, RADIATOR

1B3-12462-00-00

Unavailable

50

PIPE 2

4XY-12482-00-00

Unavailable

51

O-RING (716)

93210-18417-00

Unavailable

52

BOLT,SOCKET

91317-06012-00

Unavailable

53

BOLT, FLANGE(4MY)

95027-06012-00

Unavailable

54

WASHER(6TA)

92907-06600-00

Unavailable
