Yamaha XVZ1300ATMC (ROYAL STAR TOUR CLASSIC CA) 5EJB 2000 RADIATOR HOSE Diagram

#

Description
Price

1

HOSE 3

4NK-12578-00-00

Unavailable

2

CLIP (10V)

90467-23067-00

$7.49

3

HOSE CLAMP ASSY

90450-28001-00

$14.99

4

RADIATOR ASSY

4NK-12461-02-00

Unavailable

5

BLOWER ASSY

4NK-12405-01-00

Unavailable

6

PLUG,DRAIN COCK

1AA-12561-00-00

$28.99

7

GASKET

1AA-12435-00-00

$8.99

8

NUT 1

4NK-12671-00-00

Unavailable

9

BOLT, HEXAGON

97017-06012-00

$3.76

10

WASHER, SPRING

92907-06100-00

$4.25

11

WASHER(6TA)

92907-06600-00

$2.72

12

DAMPER, RADIATOR

4NK-12465-00-00

Unavailable

13

COLLAR(3GM)

90387-0609L-00

Unavailable

14

GROMMET (4L0)

90480-19283-00

$8.49

15

BOLT(8BC)

97017-06040-00

$9.49

16

WASHER(6TA)

92907-06600-00

$2.72

17

GROMMET

90480-16284-00

Unavailable

18

RADIATOR COVER ASSY 1

4NK-1240J-00-00

Unavailable

19

FRONT REFLECTOR ASSY

11H-85110-01-00

Unavailable

20

NUT, FLANGE(3GM)

95707-05500-00

Unavailable

21

BOLT, BUTTON HEAD

92017-06010-00

Unavailable

22

RADIATOR COVER ASSY 2

4NK-1240K-00-00

Unavailable

23

FRONT REFLECTOR ASSY

11H-85110-01-00

Unavailable

24

NUT, FLANGE(3GM)

95707-05500-00

Unavailable

25

BOLT, BUTTON HEAD

92017-06010-00

Unavailable

26

HOSE (L1500)

90445-090F6-00

Unavailable

27

CLIP 101235600

90467-08003-00

Unavailable

28

HOSE 1

4NK-12576-00-00

Unavailable

29

CLIP (10V)

90467-23067-00

$7.49

30

HOSE CLAMP ASSY

90450-32015-00

Unavailable

31

HOSE 4 (L105.6)

4NK-12579-00-00

Unavailable

32

HOSE CLAMP ASSY(3GM)

90450-38040-00

Unavailable

33

HOSE 2

4NK-12577-00-00

Unavailable

34

CLIP (10V)

90467-23067-00

$7.49

35

COVER 1

26H-1246A-03-00

Unavailable

36

COVER 2

4YE-1246E-00-00

Unavailable

37

GASKET, HOUSING COVER 2

26H-12428-00-00

Unavailable

38

BOLT, SOCKET

91314-06016-00

Unavailable

39

STAY

4NK-14413-00-00

Unavailable

40

STAY 2

4NK-14414-00-00

Unavailable

41

GASKET, HOUSING COVER 1

26H-12427-00-00

Unavailable

42

PIPE, BREATHER 1

4NK-11166-00-00

Unavailable

43

CLIP (371)

90467-14015-00

Unavailable

44

BOLT, SOCKET

91314-06040-00

Unavailable

45

BOLT, SOCKET

91314-06040-00

Unavailable

46

HOSE 6

4NK-12589-00-00

Unavailable

47

HOSE CLAMP ASSY

90450-28001-00

$14.99

48

PIPE 4

4NK-12484-00-00

Unavailable

49

O-RING (716)

93210-18417-00

Unavailable

50

BOLT,SOCKET

91317-06010-00

Unavailable

51

HOSE 5

4NK-12588-00-00

Unavailable

52

HOSE CLAMP ASSY(3GM)

90450-38040-00

Unavailable

53

HOSE 7

4YE-12551-00-00

Unavailable

54

CLIP(3BM)

90467-10135-00

Unavailable

55

BOLT, FLANGE

95817-06012-00

Unavailable

56

PIPE 1

4NK-12481-00-00

Unavailable

57

CONDUCTION ASSY

4NK-12590-00-00

Unavailable

58

CAP, RADIATOR

1B3-12462-00-00

Unavailable

59

PIPE 2

4NK-12482-00-00

Unavailable

60

O-RING (716)

93210-18417-00

Unavailable

61

BOLT,SOCKET

91317-06012-00

Unavailable
