Yamaha XVS65WC-M (V STAR 650 CUSTOM MIDNIGHT CA) 5S11 2007 DRIVE SHAFT Diagram

#

Description
Price

1

SHAFT DRIVE SUB ASSY

5FB-W4617-00-00

Unavailable

2

SEAL, HUB DUST

1J7-25319-02-00

$27.99

3

BOLT, STUD (5E5)

90116-10361-00

Unavailable

4

BOLT, WITH WASHER(72H)

97527-08525-00

$6.99

5

COLLAR, GUIDE

22U-46153-00-00

Unavailable

6

OIL SEAL (30X42X7-1J7)

93101-30084-00

$18.99

7

BRG,CYL-CAL ROLLER 80G KY

93311-43729-00

Unavailable

8

BEARING ASSY

2H7-46102-00-00

$58.99

9

SHIM, THRUST (0.30T)

1J7-17537-Y0-30

$4.47

9

SHIM, THRUST (0.40T)

1J7-17537-Y0-40

$4.47

9

SHIM, THRUST (0.50T)

1J7-17537-Y0-50

$4.47

10

BRG,R-B 6305RB1 62MM 245G KY

93306-30533-00

$137.99

11

RETAINER, BEARING

4H7-46125-00-00

$62.99

12

O-RING (4H7)

93210-60426-00

$10.49

13

OIL SEAL (4H7)

93101-38098-00

$17.99

14

COLLAR

90387-25017-00

Unavailable

14

. COLLAR

90387-256G9-00

Unavailable

15

SEAL 1

5FB-46136-00-00

Unavailable

15

SEAL 1

5FB-46136-00-00

Unavailable

16

HOUSING, BEARING

22U-46152-00-00

Unavailable

17

SHIM, RING GEAR

22U-46117-00-25

Unavailable

17

SHIM, RING GEAR

22U-46117-00-30

Unavailable

17

SHIM, RING GEAR

22U-46117-00-40

Unavailable

18

BEARING, CYLINDRICAL (22U)

93316-01301-00

Unavailable

19

WASHER, THRUST

22U-46118-00-12

Unavailable

19

WASHER, THRUST

22U-46118-00-14

Unavailable

19

WASHER, THRUST

22U-46118-00-16

Unavailable

19

WASHER, THRUST

22U-46118-00-18

Unavailable

19

WASHER, THRUST

22U-46118-00-20

Unavailable

20

O-RING (22U)

93211-39569-00

Unavailable

21

BOLT, FLANGE(3GD)

95817-10025-00

Unavailable

22

OIL SEAL (22U)

93102-65277-00

Unavailable

23

PLUG, STRAIGHT SCREW(3FA)

90340-14132-00

Unavailable

24

GASKET

214-11198-01-00

Unavailable

25

BREATHER COMP.

56W-17590-00-00

Unavailable

26

COVER, DUST

35C-46297-00-00

Unavailable

27

COUPLING, GEAR

22U-46123-00-00

Unavailable

28

SHAFT DRIVE ASSY

5FB-46171-00-00

Unavailable

28

SHAFT DRIVE ASSY

5FB-46171-00-00

Unavailable

29

CIRCLIP(13H)

99009-18400-00

Unavailable

30

SEAL 2

5FB-46137-00-00

Unavailable

30

SEAL 2

5FB-46137-00-00

Unavailable

31

CIRCLIP (537)

93410-22039-00

Unavailable

32

SPRING, COMPRESSION (22U)

90501-15722-00

Unavailable

33

NUT, CROWN(2GG)

90176-10075-00

Unavailable

34

WASHER, PLATE

92990-10600-00

Unavailable

35

COVER, HOUSING

4TR-46154-00-00

Unavailable

36

COLLAR(4TR)

90387-1510D-00

Unavailable

37

CROSS JOINT COMP.

4X7-46180-00-00

Unavailable

38

BEARING(2HR)

93399-99926-00

Unavailable

39

CIRCLIP (4X7)

93440-20088-00

Unavailable
