Yamaha XVS650MC (V-STAR CUSTOM CA) 5FBB 2000 CRANKCASE Diagram

#

Description
Price

1

CRANKCASE ASSY

4TR-15100-19-00

$721.99

2

PLANE BEARING, CRANKSHAFT 1

22U-11416-80-00

$45.99

2

PLANE BEARING, CRANKSHAFT 1

22U-11416-90-00

Unavailable

3

PIN, DOWEL(MH0)

91815-16017-00

$8.49

4

BOLT, STUD(4TR)

90116-10611-00

Unavailable

5

BOLT, STUD (22U)

90116-08404-00

$8.49

6

PIN, DOWEL

99530-14016-00

$3.80

7

COLLAR (1L9)

90387-16547-00

$9.49

8

O-RING (1L9)

93210-18322-00

$5.60

9

BOLT, STUD (22U)

90116-10405-00

$17.99

10

BOLT, STUD (22U)

90116-08404-00

$8.49

11

PIN, DOWEL

99530-14016-00

$3.80

12

COLLAR (1L9)

90387-16547-00

$9.49

13

O-RING (1L9)

93210-18322-00

$5.60

14

COLLAR (1L9)

90387-16547-00

$9.49

15

O-RING (1L9)

93210-18322-00

$5.60

16

BOLT, SOCKET

91314-08060-00

Unavailable

17

BOLT, HEXAGON SOCKET HEAD

90110-08003-00

Unavailable

18

BOLT, SOCKET

91314-08100-00

Unavailable

19

BOLT,SOCKET

91317-06095-00

Unavailable

20

BOLT,SOCKET

91380-06045-00

Unavailable

21

BOLT,SOCKET

91317-06045-00

Unavailable

22

BOLT,SOCKET

91314-06055-00

Unavailable

23

PLATE, BEARING COVER

11H-15383-02-00

Unavailable

24

SCREW, COUNTERSUNK (22U)

90151-08022-00

Unavailable

25

SCREW

90149-08013-00

Unavailable

26

HOLDER, CLUTCH CABLE

22U-15441-02-00

Unavailable

27

PLUG, STRAIGHT SCREW(3FA)

90340-14132-00

Unavailable

28

GASKET

214-11198-01-00

Unavailable
