Yamaha XVS650LC (V-STAR CUSTOM CA) 5FB8 1999 ELECTRICAL 2 Diagram

#

Description
Price

1

IGNITION COIL ASSY

4VR-82320-00-00

$136.03

2

SCREW, PAN HEAD

98517-05020-00

$1.26

3

WASHER(1RW)

92907-05600-00

$0.77

4

IGNITION COIL ASSY

4VR-82320-00-00

$136.03

5

SCREW, PAN HEAD

98517-05020-00

$1.26

6

WASHER(1RW)

92907-05600-00

$0.77

7

CLAMP(4GY)

90464-10190-00

$6.76

8

CLAMP(7LY)

90464-05141-00

$2.07

9

PLUG CAP ASSY

4XY-82370-00-00

$67.71

10

PLUG CAP ASSY

4VW-82370-00-00

$58.47

11

NEUTRAL SWITCH ASSY

1L9-82540-00-00

$37.09

12

O-RING (371)

93210-29196-00

$6.02

13

SCREW(3HX)

90149-05245-00

$5.76

14

WIRE, SUB LEAD

4TR-82509-00-00

$7.45

15

IGNITOR UNIT ASSY

5BN-82305-01-00

Unavailable

16

SCREW, TAPPING

97707-60020-00

$0.33

17

PLUG(4BP)

90338-08226-00

Unavailable

18

FLASHER RELAY ASSY

2UJ-83350-01-00

Unavailable

19

HORN

55V-83371-00-00

Unavailable

20

BOLT, WASHER BASED

90105-082A5-00

Unavailable
