Yamaha XVS650ATRC (V-STAR SILVERADO CA) 5SCC 2003 SIDE COVER Diagram
#
Description
Price
1
BOX COMP.
4TR-2160A-00-00
Unavailable
3
BOX, BATTERY
4TR-2177G-02-00
Unavailable
5
STAY, SIDE COVER 1
5BN-2172E-00-00
Unavailable
6
RIVET, BLIND
90267-32198-00
Unavailable
8
NUT, SPRING(4ES)
90183-06069-00
Unavailable
12
COVER, SIDE 1 (DEEP SCARLET)
5BN-21711-10-KU
Unavailable
13
DAMPER
4TR-21717-00-00
Unavailable
16
NUT, HEXAGON (1E6)
90170-22187-00
Unavailable
17
GROMMET (1E6)
90480-24186-00
Unavailable
18
COVER, SIDE 2 (DEEP SCARLET)
5BN-21721-00-KU
Unavailable
19
PROTECTOR 5
84M-77555-00-00
Unavailable
20
GROMMET(4BH)
90480-01559-00
Unavailable
22
SCREW(4DN)
90149-06302-00
Unavailable
23
COVER, SIDE 3
5BN-21731-00-00
Unavailable
24
BOLT,SOCKET HEAD
91314-06012-00
Unavailable
25
BOLT,SOCKET HEAD
91314-06020-00
Unavailable
26
GROMMET (4N0)
90480-10289-00
Unavailable
27
COLLAR(4DN)
90387-0600V-00
Unavailable
28
WASHER PLATE 256216150000
90201-06062-00
Unavailable
29
COVER, SIDE 4
4VR-21741-00-00
Unavailable
30
BOLT, HEXAGON SOCKET HEAD(3HE)
90110-06200-00
Unavailable
31
EMBLEM, YAMAHA
99247-00080-00
Unavailable
32
EMBLEM, YAMAHA
99247-00080-00
Unavailable
33
IGNITION COIL ASSY
4TR-28100-01-00
Unavailable
