Yamaha XVS11AWVC (V STAR 1100 CLASSIC CAST CA) 5YSJ 2006 FRONT BRAKE CALIPER Diagram

DISC BRAKE ASSY

5PX-2581T-10-00

Unavailable

BOLT,HEX. SOCKET BUTTON

90111-08057-00

$1.91

CALIPER ASSY (LEFT)

5KS-2580T-01-00

Unavailable

PISTON ASSY, CALIPER

5KS-25802-00-00

$58.47

CALIPER SEAL KIT

4HC-25803-50-00

$51.55

PIN, SLIDE

5JW-25914-10-00

$17.93

BOOT 2

4TT-25937-00-00

$13.33

BRAKE PAD KIT

5VU-25805-00-00

$40.09

SUPPORT, PAD

4BP-25919-00-00

$27.53

SPRING, ANTI RATTLE

3YX-25929-00-00

Unavailable

BLEED SCREW KIT

15B-W0048-00-00

$16.89

CALIPER ASSY (RIGHT)

5KS-2580U-01-00

Unavailable

PISTON ASSY, CALIPER

5KS-25802-00-00

$58.47

CALIPER SEAL KIT

4HC-25803-50-00

$51.55

PIN, SLIDE

5JW-25914-10-00

$17.93

BOOT 2

4TT-25937-00-00

$13.33

BRAKE PAD KIT

5VU-25805-00-00

$40.09

SUPPORT, PAD

4BP-25919-00-00

$27.53

SPRING, ANTI RATTLE

3YX-25929-00-00

Unavailable

BLEED SCREW KIT

15B-W0048-00-00

$16.89

BOLT, WASHER BASED(3VD)

90105-10638-00

Unavailable
