Yamaha XVS11AWTC (V STAR 1100 CLASSIC CA) 5YS9 2005 CYLINDER HEAD Diagram

#

Description
Price

1

CYLINDER HEAD ASSY

5YS-11101-01-00

Unavailable

2

CIRCLIP (4X7)

93440-14086-00

$9.49

3

GUIDE, INTAKE VALVE (1ST O/S)

4X7-11133-10-00

$69.99

4

BOLT, STUD 3

95617-08625-00

$8.49

5

PIN, DOWEL(3EF)

91817-30011-00

$12.49

6

GASKET, CYLINDER HEAD 1

5EL-11181-00-00

$58.99

7

BOLT, CYLINDER HOLDING 3

4X7-11363-01-00

Unavailable

8

BOLT,STUD

90116-12350-00

Unavailable

9

BOLT, STUD (4X7)

90116-10344-00

$13.99

10

NUT (4X7)

90179-12326-00

$10.49

11

NUT (4X7)

90179-12325-00

$5.60

12

NUT, CROWN(2GG)

90176-10075-00

$8.49

13

WASHER, PLATE (26H)

90201-102G9-00

$9.49

14

BOLT, SOCKET

91314-08050-00

$7.49

15

WASHER(6TA)

92907-08600-00

$3.03

16

COVER, CYLINDER HEAD SIDE 4

5YS-1111H-00-00

Unavailable

17

BOLT, SOCKET

91314-06035-00

Unavailable

18

COVER, CYLINDER HEAD SIDE 1

5YS-11185-00-00

Unavailable

19

PLATE, BREATHER

42X-11165-00-00

Unavailable

20

O-RING (4X7)

93210-92448-00

Unavailable

21

BOLT, SOCKET

91314-06035-00

Unavailable

22

COVER, CYLINDER HEAD SIDE 2

42H-11186-02-00

Unavailable

23

COVER, CYLINDER HEAD SIDE 3

5EL-11187-01-00

Unavailable

24

COVER, CYLINDER HEAD SIDE 3

4X7-11187-02-00

Unavailable

25

O-RING (4X7)

93210-62446-00

Unavailable

26

CLAMP

90465-10029-00

Unavailable

27

BOLT, SOCKET

91314-06016-00

Unavailable

28

PLATE

4X7-1111F-00-00

Unavailable

29

BOLT, HEXAGON

97017-08020-00

Unavailable

30

BOLT, UNION

90401-16002-00

Unavailable

31

GASKET (4X7)

90430-17168-00

Unavailable

32

BPR7ES NGK - 4/PACK

BPR-7ES00-40-00

Unavailable

33

COVER

5EL-1112M-00-00

Unavailable
