Yamaha XVS1100NC (V-STAR 1100 CUSTOM CA) 5PB5 2001 REAR WHEEL Diagram
#
Description
Price
1
HUB, REAR
5EL-25311-00-00
Unavailable
2
COLLAR(1FN)
90387-173M5-00
Unavailable
14
RIM
94445-15607-00
Unavailable
16
TIRE (170/80-15 M/C 77S G546)
94117-15008-00
Unavailable
16
TIRE (170/80-15 M/C 77S K555)
94117-1508W-00
Unavailable
17
TUBE(4TR)
94217-15298-00
Unavailable
17
TUBE(4TR)
94217-15298-00
Unavailable
18
BAND, RIM
94317-15181-00
Unavailable
18
BAND, RIM
94317-15181-00
Unavailable
19
AXLE, WHEEL
5EL-25381-10-00
Unavailable
20
WASHER, PLATE(3LD)
90201-160T2-00
Unavailable
21
NUT, FLANGE (4PT)
95604-16200-00
Unavailable
22
COLLAR (3HE)
90387-177Y4-00
Unavailable
23
COLLAR, WHEEL
4H7-25377-00-00
Unavailable
