Yamaha XVS1100NC (V-STAR 1100 CUSTOM CA) 5PB5 2001 METER Diagram
#
Description
Price
1
SPEEDOMETER ASSY
5PB-83500-11-00
Unavailable
3
BRACKET, METER
5EL-83519-00-00
Unavailable
4
DAMPER
4NK-83523-00-00
Unavailable
6
BULB (12V-1.4W, T6.5)
4NK-83517-00-00
Unavailable
10
SCREW, TRUSS TAP.
97707-40012-00
Unavailable
11
SOCKET CORD ASSY
5EL-83509-00-00
Unavailable
15
MOLE 2
5EL-28346-00-00
Unavailable
16
GUIDE
1FK-2171H-00-00
Unavailable
17
WASHER, PLATE (4H7)
90201-061A5-00
Unavailable
18
NUT, HEXAGON
95317-05600-00
Unavailable
