Yamaha XV535LC (VIRAGO 535 CA) 4YNA 1999 REAR ARM SUSPENSION Diagram

#

Description
Price

1

REAR ARM COMP.

2GV-22110-00-35

Unavailable

2

BEARING (4X7)

93320-32403-00

$46.99

3

BUSH 2

4X7-22124-00-00

$75.99

4

COVER, THRUST 2

4X7-22129-00-00

$22.99

5

WASHER

3YF-22149-00-00

$8.99

6

SHAFT, PIVOT

4X7-22141-00-00

Unavailable

7

WASHER, LOCK

90215-16181-00

Unavailable

8

BOOT, RUBBER

22U-22189-00-00

Unavailable

9

BOLT(3JP)

97024-08035-00

$7.49

10

YBS67-8 WASHER, SPRING

92990-08100-00

$5.60

11

SHOCK ABSORBER ASSEMBLY, REAR

2YL-22210-01-00

Unavailable

12

BUSH, REAR SHOCK ABSORBER

2GV-22216-00-00

$14.49

13

. COLLAR, DISTANCE

2GV-22253-00-00

Unavailable

14

BUSH, REAR SHOCK ABSORBER

4KG-22216-00-00

$3.90

15

SHOCK ABSORBER ASSEMBLY, REAR

2YL-22220-01-00

Unavailable

16

BUSH, REAR SHOCK ABSORBER

4KG-22216-00-00

$3.90

17

COLLAR, DISTANCE

5M0-22253-00-00

Unavailable

18

BOLT, FLANGE

95817-08012-00

Unavailable

19

WASHER, PLATE(8AT)

90201-081R9-00

Unavailable

20

WASHER, PLATE(3BM)

90201-105R9-00

Unavailable

21

NUT, CROWN(3BM)

90176-10073-00

Unavailable

22

YBS67-10 WASHER, SPRING

92990-10100-00

Unavailable

23

BOLT,DOME HEAD

90106-10052-00

Unavailable
