Yamaha XV535EC (VIRAGO 535 CA) 3JC8 1993 STAND FOOTREST Diagram

#

Description
Price

1

PEDAL, BRAKE

2GV-27211-00-93

Unavailable

2

WASHER, PLATE(2GV)

90201-152L1-00

$10.49

3

CIRCLIP(1AR)

99009-15400-00

$8.49

4

BOLT, HEXAGON

97017-06025-00

$4.24

5

NUT, HEXAGON

95380-06600-00

Unavailable

6

SPRING, TENSION(1FN)

90506-20380-00

$5.60

7

CABLE, BRAKE

2GV-26351-00-00

$115.99

8

PIN, COTTER (1W2)

91701-06022-00

$2.49

9

YBS66-6 WASHER, PLAIN

92990-06200-00

$3.78

10

PIN, COTTER

91490-20025-00

$1.99

11

SPRING, (180-27236-00)

90501-10245-00

$8.49

12

PIN 1562723700

90249-12008-00

$8.49

13

NUT (25K)

90179-06411-00

$8.49

14

FRONT FOOTREST ASSY (LEFT)

1RM-27410-00-93

$205.99

15

COVER, FOOTREST

1NH-27413-00-00

$45.99

16

NUT (J17)

95380-06800-00

Unavailable

17

SPRING, TORSION(1MY)

90508-18696-00

Unavailable

18

PIN, CLEVIS (2A6)

91701-08038-00

Unavailable

19

PIN, COTTER

91490-25020-00

Unavailable

20

COLLAR(1HX)

90387-087K5-00

Unavailable

21

FRONT FOOTREST ASSY (RIGHT)

1RM-27420-00-93

Unavailable

22

COVER, FOOTREST

1NH-27413-00-00

$45.99

23

NUT (J17)

95380-06800-00

Unavailable

24

SPRING, TORSION(1MY)

90508-18696-00

Unavailable

25

PIN, CLEVIS (2A6)

91701-08038-00

Unavailable

26

PIN, COTTER

91490-25020-00

Unavailable

27

COLLAR(1HX)

90387-087K5-00

Unavailable

28

DAMPER, FOOTREST

4X7-27414-00-00

Unavailable

29

COLLAR

90387-107A7-00

Unavailable

30

WASHER, PLATE (3J6)

90201-100A1-00

Unavailable

31

PROTECTOR

2GV-27491-00-00

Unavailable

32

BOLT(3BM)

90109-100G0-00

Unavailable

33

BAR,FOOTREST 1

2GV-27471-02-00

Unavailable

34

BAR, FOOTREST 2

2GV-27472-02-00

Unavailable

35

BAND

1UA-82591-00-00

Unavailable

36

PLUG (341-26329-00)

90338-09012-00

Unavailable

37

BOLT, WASHER BASED(36Y)

90105-10312-00

Unavailable

38

NUT, FLANGE(3BM)

95704-10500-00

Unavailable

39

REAR FOOTREST ASSEMBLY 1

2NT-27430-01-00

Unavailable

40

COVER, REAR FOOTREST

1NH-27433-00-00

Unavailable

41

BOLT, BUTTON HEAD(3JP)

92014-06012-00

Unavailable

42

. WASHER, SPECIAL

2NT-27437-00-00

Unavailable

43

PIN, CLEVIS (1Y8)

91701-06032-00

Unavailable

44

PIN, COTTER

91490-20025-00

$1.99

45

SPRING, COMPRESSION (22N)

90501-12743-00

Unavailable

46

BALL

93501-04011-00

Unavailable

47

REAR FOOTREST ASSEMBLY 2

2NT-27440-01-00

Unavailable

48

COVER, REAR FOOTREST

1NH-27433-00-00

Unavailable

49

BOLT, BUTTON HEAD(3JP)

92014-06012-00

Unavailable

50

. WASHER, SPECIAL

2NT-27437-00-00

Unavailable

51

PIN, CLEVIS (1Y8)

91701-06032-00

Unavailable

52

PIN, COTTER

91490-20025-00

$1.99

53

SPRING, COMPRESSION (22N)

90501-12743-00

Unavailable

54

BALL

93501-04011-00

Unavailable

55

BOLT, FLANGE(3HP)

95817-10016-00

Unavailable

56

STAND, SIDE

2GV-27311-00-R4

Unavailable

57

BOLT(2GH)

90109-104E6-00

Unavailable

58

NUT, U

90185-10037-00

Unavailable

59

LINK, SIDE STAND

5H0-27315-00-00

Unavailable

60

SPRING, TENSION (5N8)

90506-29266-00

Unavailable
