Yamaha XV250VC (VIRAGO 250 CA) 3BGF 2006 TRANSMISSION Diagram

#

Description
Price

1

AXLE, MAIN

4DN-17411-00-00

$118.99

2

GEAR, 4TH PINION (26T)

3Y1-17141-01-00

Unavailable

3

WASHER, PLATE (3Y1)

90201-22793-00

$7.49

4

CIRCLIP (537)

93410-22039-00

$8.49

5

GEAR, 3RD PINION

3Y1-17131-01-00

Unavailable

6

GEAR, 5TH PINION

3Y1-17151-01-00

$47.99

7

GEAR, 2ND PINION (19T)

3Y1-17121-01-YX

Unavailable

8

BEARING (3Y1)

93306-20541-00

$38.99

9

OIL SEAL (3Y1)

93101-17093-00

Unavailable

10

BEARING(2JN)

93306-00315-00

$33.99

11

DRIVE AXLE ASSY

3Y1-17402-00-00

Unavailable

12

GEAR, 2ND WHEEL

3Y1-17221-02-00

$58.99

13

WASHER, PLATE(59W)

90201-253K0-00

$8.49

14

CIRCLIP (4L0)

93440-25084-00

$5.60

15

GEAR, 5TH WHEEL

4DN-17251-00-00

Unavailable

16

GEAR, 3RD WHEEL

3Y1-17231-02-00

Unavailable

17

WASHER (3J3)

90209-22191-00

Unavailable

18

CIRCLIP(JF7)

99009-25400-00

Unavailable

19

GEAR,4TH WHEEL

4DN-17241-00-00

Unavailable

20

GEAR, 1ST WHEEL

3Y1-17211-00-00

Unavailable

21

WASHER PLATE 328171160000

90201-20276-00

Unavailable

22

CIRCLIP(1AR)

99009-20400-00

Unavailable

23

BEARING (5Y1)

93306-00426-00

Unavailable

24

BEARING (3Y1)

93306-30525-00

Unavailable

25

OIL SEAL (3Y1)

93102-25208-00

Unavailable

26

SPROCKET,DRIVE 16T(3Y11746160)

93834-16100-00

Unavailable

27

HOLDER, SPROCKET

3Y1-17456-00-00

Unavailable

28

BOLT(3JP)

97017-06010-00

Unavailable
