Yamaha XV250SC (VIRAGO 250 CA) 3BGD 2004 STEERING Diagram

#

Description
Price

1

BEARING(4HC)

93399-99942-00

$85.99

2

BEARING

93399-99950-00

Unavailable

3

COVER, BALL RACE 1

4HF-23415-00-00

Unavailable

4

NUT

90179-25004-00

$24.99

5

BOLT (2A2)

90105-14102-00

$5.60

6

CR0WN, HANDLE (SILVER)

2UJ-W2341-00-35

Unavailable

7

BOLT, FLANGE(4KG)

95024-08040-00

$8.49

8

STAY, LIGHT GUARD

3DM-23164-00-00

Unavailable

9

STAY 2

3DM-2317F-00-00

Unavailable

10

HOLDER, HANDLE LOWER

42X-23442-01-38

Unavailable

11

WASHER, PLATE (4X7)

90201-105A2-00

$8.49

12

NUT, U

95617-10100-00

$8.49

13

HOLDER, HANDLE UPPER

4H7-23441-01-38

Unavailable

14

BOLT,SOCKET

91314-08025-00

$8.49

15

PLUG(42X)

90338-08163-00

$3.45

16

STAY, HEADLIGHT

2UJ-23174-01-00

Unavailable

17

BOLT, FLANGE(2UJ)

95024-06016-00

Unavailable

18

STAY 3

2UJ-2317M-00-00

Unavailable

19

emblem yamaha

3WF-2153E-41-00

Unavailable

20

BOLT, FLANGE(2UJ)

95024-06012-00

Unavailable

21

STAY

2UJ-2317E-00-00

Unavailable

22

BOLT,SOCKET

91317-06016-00

Unavailable

23

STEERING LOCK ASSY

2A6-23408-00-00

Unavailable

24

CAP, HANDLE LOCK

3DM-23484-00-00

Unavailable

25

SPRING, CONICAL (1E6)

90502-09024-00

Unavailable

26

WASHER, CONICAL SPRING (3J3)

90208-04029-00

Unavailable

27

RIVET 214234830000

90269-04003-00

Unavailable
