Yamaha XT600EBC (XT600E CA) 1991 FRONT WHEEL Diagram

#

Description
Price

1

HUB, FRONT

3TB-25111-00-98

Unavailable

2

SPACER (34L)

90560-15240-00

Unavailable

3

BEARING

93306-20205-00

$38.99

4

OIL SEAL (23X)

93102-20281-00

$14.99

5

DISC, BRAKE

3TB-2582T-00-00

Unavailable

6

BOLT, BUTTON HEAD

92017-06016-00

$8.49

7

RIM (1.85-21)

94418-21492-00

Unavailable

8

SPOKE SET, FRONT

3TB-25104-00-00

Unavailable

9

TIRE (MCS 90/90-21 54S TW41)

94109-213X0-00

Unavailable

10

TUBE 90190-21

94209-21229-00

Unavailable

11

BAND, RIM (2A6)

94330-21084-00

$16.99

12

PLUG (10V)

90338-09130-00

$7.49

13

BALANCER, WHEEL

3HT-25398-00-00

$7.99

14

RING 2

3TB-25336-00-00

Unavailable

15

COLLAR (34L)

90387-152J3-00

$21.99

16

COVER, HUB DUST

322-25118-00-00

Unavailable

17

AXLE, WHEEL

4GY-25181-00-00

Unavailable

18

GEAR UNIT ASSY

34L-25190-01-00

Unavailable

19

CALIPER ASSY (LEFT)

4PT-2580T-00-00

Unavailable

20

PISTON ASSY, CALIPER

3TB-W0057-00-00

Unavailable

21

CALIPER SEAL KIT

3GD-W0047-00-00

Unavailable

22

BOOT 2

1UY-25937-51-00

Unavailable

23

BOOT, CALIPER

3JD-25917-00-00

Unavailable

24

. SUPPORT, PAD

3TB-25919-00-00

Unavailable

25

BLEED SCREW KIT

36Y-W0048-00-00

Unavailable

26

BRAKE PAD KIT

4PT-W0045-00-00

Unavailable

27

PIN, PAD

3TB-25933-00-00

Unavailable

28

BOLT, WASHER BASED(4KM)

90105-10778-00

Unavailable

29

COVER 1

1VJ-25715-00-00

Unavailable

30

SCREW(36F)

90149-06194-00

Unavailable
