1976 Yamaha XT500 (XT500C) Kick - Starter Diagram

← All diagrams

Find the part on the Kick - Starter diagram for your 1976 Yamaha XT500 (XT500C), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1976 Yamaha XT500 (XT500C) Kick - Starter Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CRANK, KICK

(583-15611-00-93)

1
Out of stock

2

COVER, KICK LEVER

156-15618-01-00

1

$6.43

In stock

3

BOSS, KICK CRANK

583-15621-00-00

1
Out of stock

4

WASHER PLATE 278156130000

90201-15234-00

1

$6.78

In stock

5

CIRCLIP

99006-10600-00

1

$6.91

In stock

6

BALL (12R)

93507-32031-00

1
Out of stock

7

SPRING COMPRESSION278156220000

90501-12081-00

1
Out of stock

8

BOLT, HEXAGON

97013-08030-00

1

$3.20

In stock

9

OIL SEAL (25X35X7-256)

93102-25064-00

1
Out of stock

10

WASHER, PLATE(1FK)

90201-256K6-00

—

$3.49

In stock

11

CIRCLIP(JF7)

99009-25400-00

1

$6.68

In stock

12

SPACER

(90560-25154-00)

1
Out of stock

13

SPRING, TORSION (583 KICK)

90508-32280-00

1
Out of stock

14

COVER, SPRING

(583-15676-00-00)

1
Out of stock

15

CIRCLIP (4L0)

93440-25084-00

1

$3.96

In stock

16

GEAR, KICK

583-15641-00-00

—
Out of stock

17

WASHER, PLATE(59W)

90201-253K0-00

—

$6.18

In stock

18

CIRCLIP

93440-25020-00

—
Out of stock

19

WHEEL, RACHET

583-15671-00-00

—
Out of stock

20

SPRING COMPRESSION363156750000

90501-23143-00

—
Out of stock

21

COVER, SPRING

363-15676-00-00

—
Out of stock

22

CIRCLIP(1EY)

99009-19400-00

—

$6.17

In stock

23

WASHER PLATE 168171160000

90201-20278-00

—
Out of stock

24

AXLE, KICK

583-15661-00-00

—
Out of stock

25

STOPPER

434-15668-00-00

—
Out of stock

26

GUIDE, RACHET WHEEL

583-15674-00-00

—
Out of stock

27

WASHER, LOCK

363-15686-00-00

—
Out of stock

28

BOLT, HEXAGON DEEP RECESS

97D95-06016-00

—

$1.91

In stock
