Yamaha XT225VC (XT225 CA) 5RKD 2006 CYLINDER HEAD Diagram

#

Description
Price

1

CYLINDER HEAD ASSY

5RK-11101-00-00

Unavailable

2

GUIDE, INTAKE VALVE

5H0-11133-11-00

$63.99

3

CIRCLIP (4G0)

93440-10085-00

$8.49

4

COLLAR

90385-12039-00

$11.49

5

SCREW

90153-06029-00

$10.49

6

GASKET 256113960000

90430-06014-00

Unavailable

7

GASKET, CYLINDER HEAD 1

59V-11181-00-00

$38.99

8

PIN, DOWEL

99530-14016-00

$3.80

9

PIN, DOWEL(4XL)

93612-16254-00

$5.60

10

GASKET

90430-12243-00

$45.99

11

BOLT, FLANGE

90105-08160-00

$7.49

12

WASHER, PLATE

90201-080L7-00

$4.82

13

BOLT, SOCKET

91317-08045-00

Unavailable

14

BREATHER ASSY

5RK-11160-01-00

Unavailable

15

PLATE, BREATHER

5MP-11165-00-00

Unavailable

16

O-RING (4X7)

93210-92448-00

Unavailable

17

BOLT, BUTTON HEAD

92017-06012-00

Unavailable

18

O-RING (5H0)

93211-05471-00

Unavailable

19

. BOLT, FLANGE

95027-06020-00

Unavailable

20

COVER, CYLINDER HEAD SIDE 2

15A-11186-00-00

Unavailable

21

COVER, CYLINDER HEAD SIDE 3

15A-11187-00-00

Unavailable

22

O-RING

93210-57634-00

Unavailable

23

BOLT,SOCKET

91317-06018-00

Unavailable

24

PLATE

5H0-1111F-00-00

Unavailable

25

BOLT, HEXAGON

97017-06012-00

Unavailable

26

WASHER, LOCK (5H0)

90215-06184-00

Unavailable

27

DR8EA NGK SPLUG 10PK

DR8-EA000-00-00

Unavailable
