Find the part on the Electrical 3 diagram for your 2023 Yamaha XSR900 (XSR900PL), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2023 Yamaha XSR900 (XSR900PL) Electrical 3 Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HYDRAULIC UNIT ASS

B5U-85930-09-00

—
Out of stock

2

BOLT, FLANGE

95817-06008-00

1
Out of stock

3

BRACKET, UNIT

B7N-85991-00-00

—
Out of stock

4

GROMET (3X3)

90480-14229-00

1
Out of stock

5

COLLAR (J10)

90387-06026-00

1
Out of stock

6

BOLT, WITH WASHER(81H)

90119-06118-00

1
Out of stock

7

BRACKET

B7N-85542-00-00

—
Out of stock

8

WASHER, PLATE (8K2)

90201-06778-00

1
Out of stock

9

NUT, CROWN(2GM)

90176-06065-00

1
Out of stock

10

BOLT, SMALL FLANGE

95027-06045-00

1
Out of stock

11

NUT, SELF-LOCKING

95617-06100-00

1
Out of stock

12

PIPE, BRAKE

B7N-25871-00-00

—
Out of stock

13

PIPE, BRAKE 2

B7N-25882-00-00

—
Out of stock

14

JOINT

B7N-25885-00-00

—
Out of stock

15

BOLT, BUTTON HEAD

92012-06035-00

1
Out of stock

16

WHEEL SENSOR ASSY,

B7N-85970-00-00

—
Out of stock

17

BOLT, BUTTON HEAD

92017-06014-00

—
Out of stock

18

CLAMP

90464-16003-00

—
Out of stock

19

HOLDER, CABLE

2CR-23317-00-00

—
Out of stock

20

BOLT, BUTTON HEAD

92017-06014-00

—
Out of stock

21

CLAMP

90464-14013-00

—
Out of stock

22

WHEEL SENSOR ASSY,

B5U-85980-00-00

—
Out of stock

23

BOLT, BUTTON HEAD(4NK)

92014-06014-00

—
Out of stock

24

CLAMP(4GL)

90464-10233-00

—
Out of stock
