Description

Price

1

GUARD, MUD

BMC-21629-00-00

$138.99

2

GROMMET

90480-16X01-00

Unavailable

3

GROMMET (3AB)

90480-25482-00

$3.18

4

NUT

B2G-21791-00-00

$25.99

5

TUNING FORK MARK

4KN-2836B-10-00

$18.49

6

NUT SPRING

90183-05X04-00

Unavailable

7

BOLT,HEX. SOCKET BUTTON

90111-06095-00

$8.49

8

CLAMP(74L)

90461-11099-00

$1.54

9

SCREW, TRUSS TAP.

97707-40012-00

Unavailable

10

COVER, REAR FENDER 1

B34-F163A-00-00

$75.99

11

SCREW, TAPPING

90167-05079-00

$4.14

12

COVER, SIDE 1

BMC-21711-00-00

$62.99

13

GROMMET(4DN)

90480-01558-00

$4.19

14

DAMPER, PLATE

90520-03017-00

$1.59

15

BOLT

90111-05011-00

$5.60

16

NUT SPRING

90183-05X04-00

Unavailable

17

COVER, SIDE 2

BMC-21721-00-00

Unavailable

18

GROMMET(4DN)

90480-01558-00

$4.19

19

DAMPER, PLATE

90520-03017-00

$1.59

20

BOLT

90111-05011-00

$5.60

21

NUT SPRING

90183-05X04-00

Unavailable

22

COVER, SIDE 3

BMC-21731-00-P0

Unavailable

23

BOLT(3JP)

90111-05012-00

Unavailable

24

COVER, SIDE 4

BMC-21741-00-P0

Unavailable

25

BOLT(3JP)

90111-05012-00

Unavailable

26

SCOOP, AIR 1

BMC-2137W-00-00

Unavailable

27

BOLT

90111-05011-00

$5.60

28

SCOOP, AIR 2

BMC-2137X-00-00

Unavailable

29

DAMPER 1

4HM-21638-00-00

Unavailable

30

BOLT

90111-05011-00

$5.60

31

GRILL, AIR INTAKE

BMC-2837R-00-00

Unavailable

32

NUT, SPRING (6E5)

90183-05M02-00

Unavailable

Yamaha XSR700SCB (XSR700 CA) BMCM 2025 SIDE COVER Diagram

GUARD, MUD

GROMMET

GROMMET (3AB)

NUT

TUNING FORK MARK

NUT SPRING

BOLT,HEX. SOCKET BUTTON

CLAMP(74L)

SCREW, TRUSS TAP.

COVER, REAR FENDER 1

SCREW, TAPPING

COVER, SIDE 1

GROMMET(4DN)

DAMPER, PLATE

BOLT

NUT SPRING

COVER, SIDE 2

GROMMET(4DN)

DAMPER, PLATE

BOLT

NUT SPRING

COVER, SIDE 3

BOLT(3JP)

COVER, SIDE 4

BOLT(3JP)

SCOOP, AIR 1

BOLT

SCOOP, AIR 2

DAMPER 1

BOLT

GRILL, AIR INTAKE

NUT, SPRING (6E5)
