REAR WHEEL
Yamaha XS750D (XS750) 1977 REAR WHEEL Diagram
#
1
WHEEL, CAST REAR
(1J7-W2533-10-00)
Unavailable
1
WHEEL, CAST REAR
2G2-W2533-21-00
Unavailable
1
WHEEL, CAST REAR
2G2-W2533-21-00
Unavailable
2
400X18 BS 21R
(94140-18346-00)
Unavailable
4
SPACER, BEARING
(1J7-25317-00-00)
Unavailable
5
FLANGE, SPACER 1
(1J7-25115-01-00)
Unavailable
8
COLLAR
90387-20741-00
Unavailable
11
COVER, PLATE
(1J7-25327-00-00)
Unavailable
11
COVER, PLATE
(1J7-25327-10-00)
Unavailable
12
SCREW, PAN HEAD(6B0)
97885-05016-00
Unavailable
13
YBS67-4 WASHER, SPRING
92990-04100-00
Unavailable
13
YBS67-5 WASHER, SPRING
92990-05100-00
Unavailable
14
YBS66-4 WASHER, PLAIN
92990-04200-00
Unavailable
14
. WASHER, PLAIN
92990-05200-00
Unavailable
15
BEARING(3BC)
93306-30437-00
Unavailable
16
OIL SEAL (27X52X5-256)
93104-27026-00
Unavailable
17
COLLAR, WHEEL
1J7-25377-00-00
Unavailable
18
COVER, HUB DUST
1J7-25367-00-00
Unavailable
19
COLLAR
(90387-20542-00)
Unavailable
20
BAR, TENSION
(1J7-25371-00-00)
Unavailable
21
AXLE, WHEEL
1J7-25381-00-00
Unavailable
22
PIN, COTTER
91490-40045-00
Unavailable
23
WASHER, PLATE (1J7)
90201-18620-00
Unavailable
24
NUT, CASTLE
90171-18043-00
Unavailable
25
SPACER, TORQ.STOP (92901-08100)
1J7-25374-00-00
Unavailable
26
WASHER, PLATE (5J0)
90201-085E6-00
Unavailable
27
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
28
. NUT
95380-08700-00
Unavailable
29
PIN, COTTER
91490-20025-00
Unavailable
30
BALANCER, WHEEL
5MT-25398-00-00
Unavailable
30
BALANCER, WHEEL
5MT-25398-00-00
Unavailable
